POWERING TOMORROW’S CONNECTIONS TOGETHER.

• Board-to-board and Wire-to-board with AWG34 available
• Board-to-board stack height 5 – 19 mm
• High wipe lenght of 1,9 mm

• Hermaphroditic design with a 0.8 mm pitch
• High current rating up to 2.7 A
• High wipe length of 1.5 mm

• High current rating up to 3.6 A
• High shock and vibration resistance
• Comprehensive range with wire-to-board AWG 30-32

• High degree of robustness and reliability
• High wipe length of 2,5 mm
• Comprehensive portfolio

• High current rating up to 3.6 A
• High shock and vibration resistance
• Comprehensive range with wire-to-board AWG 30-32

• High current rating up to 3.9 A
• High shock and vibration resistance
• Comprehensive range with wire-to-board AWG 28-30

• 6x6 mm tactile switch – SMT w/100gf actuator
• 7.5x7.5 mm tactile switch – SMT, 5 positions

• High speed data rate up to 25 Gbit/s
• EMC improved shielding solution
• Meets 100 Gbit Ethernet standard IEEE 802.3ba

• Current rating up to 18 A
• High design robustness
• High wipe length of 1.5 mm

• 2.5 mm pitch; Max current 4 A; Soldering temp – reflow capable 260°C; Halogen/Lead free
• 3.5 mm pitch; Max current 8 A; Soldering temp – reflow capable 260°C; Halogen/Lead free
• 3.81 mm pitch; Max current 8 A; Soldering temp – reflow capable 260°C; Halogen/Lead free

• 3-point box contact
• Robust termination and vibration resistant
• Clear mating sound
• Current up to 5 A

• 3-point box contact
• Robust termination and vibration resistant
• Clear mating sound
• Current rating up to 15 A

• 3-point box contact
• Robust termination and vibration resistant
• Clear mating sound
• Current rating up to 45 A

• The industry’s smallest IDC connector
• Two contact points structure provides for high contact reliability
• Housing colors indicate applicable wire range

• The industry’s smallest IDC connector
• 4-position RITS connector is e-CON approved as the industry standard connector

• Allow simultaneous multi-point connections with a single press
• Remove the need for wire preparation (stripping) before termination
• Facilitate completely automated board assembly
• Ultra-low profile, microminiature PCB layout
• Up to 14 A current carrying capacity
• Dual IDC contacts
• User-friendly wire termination
• Pick and place tape is available for SMT process

• Standard Density Connector: Signals up to 25 A (Sealable)
• Multiple combinations of signal and coaxial circuits in the same housing possible using durable Multimate size 16 contacts
• Sealable to IEC IP67
• UV-Resistant version available

• Combination of Standard and Power Density Connector: signals up to 25 A, power up to 50 A
• POWERBAND contacts and the reliability of signal carrying, low current Type III+ contacts
• Sealable to IEC IP65 or IP67
• UV-Resistant version available

• Compact, high contact density, environmentally sealed connectors
• Uses existing Mini-Universal MATE-N-LOK crimp, snap in contacts
• 1/4-turn coupling ring with positive lock and alignment features
• Sealable to IEC IP 67

• A, B, D and X-code
• Vertical and R/A variants
• Machined and S&F Contacts

• Broad portfolio connectors and cord sets
• Panel, PCB, cable, and FI connectors solutions for power and sensor, bus and Ethernet communication

• High temperature range
• High corrosion resistivity
• Reflow solderable

• Ruggedized, vibration-proofed industrial connector
• Small form factor (compared to RJ45)
• Robust locking system

• Cable glands: high ingress protection ratings; Standard & specialized applications: EMC, Hygienic versions
• Ventilation cable glands: 2 in 1 product, cable gland and ventilation plug; Balances pressure differences between inner housing and the outside environment

• Type 2 and 4 high safety level light curtains
• Reliable and compact

• 22 mm Emergency Stop switch
• 2 NC contact blocks, IP65 rated

• 22.5 mm mounting – IP67 rated
• ILE Series LED Indicator – Green
• IPE Series Panel Push Button – Flush, Red
• ISE Series Panel Selector – Lever style

• PT relay – 2 pole 5 A, 4 pole 3 A, 2 and 4 form C (CO) contacts
• DC and AC coils that can be identified by LED colors
• Optional LED and protection diode
• SNR package – 1CO with 6 A rated current – for use combined with socket, UL, VDE certified
• Suitable Applications: Electrical control cabinet, Machine Tools, Automatic production line, Interface technology

• Slim interface, power relay for up to 8 A in PLC applications
• Revolutionary new contact system
• 10x higher lifetime at common DC loads
• Rated for ambient temperature up to 105 °C
• UL and VDE certified

• 1 pole 10 A, 1 from C (CO) or 1 form A (NO) contact
• For inrush peak currents up to 65 A; TV 4 rating
• Ambient temperature up to 85 °C
• Anti-hazardous location versions available

• RT1: Robust switching: 16 A at 250 VAC (1 NO/CO) for demanding loads with long life in harsh conditions; Compact design: only 15 mm height for space-saving modules; Versatile range: monostable/bistable coils, multiple contact options, and high inrush performance
• RT2: High-capacity switching: 8 A at 250 VAC (2 NO/2 CO) for demanding loads under harsh environments; Durable design: long electrical life for reliable performance on cyclic and inductive loads, minimizing downtime and maintenance

• 6 and 4 pole contact set of Force guided contacts acc. to IEC 61508-2
• Fully compatible to SR6 relay series
• Reduced relay height, less coil power

• Slim profile for low-profile safety modules
• Only 10.8 mm height for loads up to 6 A

• 2 pole contact set of Force guided contacts acc. to IEC 61508-2
• Very slim design with horizontal and vertical PCB mounting for the most miniaturized applications

• IM Series: Flexible design: wide range of terminal types for PCB space-saving; Versatile options: variants include monostable/bistable, low coil power, high dielectric, high current (up to 5 A), high contact stability, bifurcated or single contact
• HF Series: High performance: RF range from DC to 6 GHz with shielded options for superior signal integrity; Broad portfolio: monostable and bistable coils with 50 Ω and 75 Ω impedance options

• Rated Currents from 0.3 to 10 A
• Fully potted design usable for ruggedized applications

• Automated production lines – 1 phase – 250 V AC – SMD terminals
• Rated currents 0.4 A to 6 A

• EMI filters for machinery and machine tool equipement
• Standard performance EMC solution
• Fast wiring with cage clamp terminals

• High temperature range
• High corrosion resistivity
• Reflow solderable

• Broad portfolio of connectors and cord sets
• Panel, PCB, cable and FI connectors
• Solutions for power, sensor, bus and Ethernet communication

• Ruggedized vibration proof industrial connector
• Small form factor (compared to RJ45)
• Robust locking system

• High ingress protection ratings
• Standard and specialized applications
• Plastic, metal, EMC, Hygienic versions

• Data transmission up to 1 Gb/s
• Power supply up to 400 W
• Current over signal pair up to 4 A (22 AWG)
• Current over power pair up to 8 A (18 AWG)

• Supports up to 10 Gbps, making it suitable for Cat6A Ethernet applications
• Supports insulation displacement contact (IDC) for easy field termination without specialized tools
• Rated for 50 V AC / 60 V DC and 0.5 A

• Excellent capability with up to 30,000 time mating cycles to provide high reliability solution
• Clever floating system enables AGV to automatic correct mating positions
• Compact design with hybrid power and signal enables the miniaturization of vehicles

• Power, signal and data hybrid
• EMC shielding
• Ethernet module with Cat5

• Space saving with hybrid connector
• 2 levels of Power and Signals
• EMC protection for signal transmission
• High density up to 86 pins in one connector (suitable H10B)

• Allow different power, signal and data combining in various modules
• 3-48 box-shaped contacts in one module, up to 6 modules per connector
• Reduced cable assembly costs by using semi-automatic or fully-automatic crimping process

• The D3100 series is the main Dynamic Series
• Widely used as industrial‚ signal and power connectors
• All connector forms are provided, from the wire-to-wire to the wire-to-board horizontal type and vertical type
• 3.81 mm pitch
• SMT versions is available

• Rugged & Cost-effective
• Well managed supply chain with lower LT.
• Secure and efficient connections
• High-performance data and power transmission
• Ease of use
• Square grid, Ractangular, Drawer Type, In-line type design

• 2-point box contact
• Secure locking and vibration resistant
• Clear mating sound
• Current rating up to 4.5 A per position
• Appl. temp -55°C – +125°C

• High current rating up to 40 A
• Various of thread sizes (English and metric)
• High flexibility of cable connection

• Power distribution up to 360 A
• Press-fit and SMD termination available
• Shock and vibration proof

• Economical solution for mitigating mains disturbances
• Reduction of mains harmonics and commutation notches
• Ensure reliability and a long service life of electrical sytems

• EMI filters for machinery and machine tool equipement
• Standard performance EMC solution
• Fast wiring with cage clamp terminals

• 1 phase and 3 phase
• Rated currents 6 A to 85 A
• Horizontal and vertical configurations
• Economy version with ferrite core
• Performance version with nanocrystalline core

• 6 and 4 pole contact set of Force guided contacts acc. to IEC 61508-2
• Fully compatible to SR6 relay series
• Reduced relay height, less coil power

• Slim interface Power relay for up to 8 A in PLC applications
• Revolutionary new contact system
• 10x more lifetime at common DC loads
• UL and VDE certified

• High Power Handling: up to 1000 W with efficient heat dissipation
• Wide Resistance Range: 0.2 Ω to 2.0 kΩ
• Rugged Design: aluminum enclosure for harsh industrial environments
• Vibration Resistant: complies with IEC 60068-2-6 and IEC 61373:2010
• Certified Quality: UL-approved cables, RoHS compliant, CE marked
• Safe and Reliable: 2500 V dielectric strength, IP-rated protection
• 1 pole 8 A, 1 form C (CO) or 1 form A (NO) or 1 form B (NC) contact
• Optimized height of 12.3 mm
• Ambient temperature up to 85°C
• Reflow version for THR mounting process
• Anti-hazardous location versions available

• Power dissipation capability up to 17 W
• Fusible styles available
• Non-flammable and solvent-resistant

• High Power Handling: up to 1000 W with efficient heat dissipation
• Wide Resistance Range: 0.2 Ω to 2.0 kΩ
• Rugged Design: aluminum enclosure for harsh industrial environments
• Vibration Resistant: complies with IEC 60068-2-6 and IEC 61373:2010
• Certified Quality: UL-approved cables, RoHS compliant, CE marked
• Safe and Reliable: 2500 V dielectric strength, IP-rated protection

• Ultra-slim aluminum housing: only 7.25 mm thick
• Voltage rating: up to 1000 V AC / 1414 V DC (with UL limits)
• Excellent insulation: ≥ 100 MΩ resistance and 4000 V surge capability.
• Durable construction: anodized aluminum for efficient heat dissipation and long-term reliability
• Flexible wiring: comes with insulated 18 AWG cables rated for 600 V and 200°C

• High degree of robustness and reliability
• High wipe length of 2,5 mm
• Comprehensive portfolio

• High speed data rate up to 25 Gbit/s
• EMC improved shielding solution
• Meets 100 Gbit Ethernet standard IEEE 802.3ba

• Current rating up to 18 A
• High design robustness
• High wipe length of 1.5 mm

• Wire-to-board flexfoil with integrated strain relief
• High current rating up to 1 A
• High temperature up to 150°C

• High current rating up to 8.7 A
• High temperature up to 150°C
• Comprehensive portfolio

• High current rating up to 12 A
• Secure color and mechanical coding
• Primary and secondary locking system

• Very compact and robust design
• Save 360° EMC shielding
• Reduction of space requirements for connectivity at motors

• Small form factor motor connectivity
• One cable solution for power and signal data
• 12-pin interface for supporting multiple applications

• Small form factor daisy chain interface for DC powered motion
• High current power, signal and STP pins
• Small mechanical footprint

• Daisy chain interface for DC powered motion
• Receptacle variants for simple cable design
• High current power, signal and STP pins

• One cable solution for direct device integration
• Solder connection for power, signal, data and data shield
• Electrical specifications meeting wired variants

• Highest robustness against corrosion given by stainless steel interface
• Support power and signal inserts from the 615 / 915 product family
• Designed for washdown areas

• Combination of Standard and Power Density Connector – economical combination of thermoplastic UL 94V-0 rated
• Connector housings and metal shells
• Compatible with MIL Spec metal housing type connectors
• Available in square flange receptacles and freehanging plug connectors

• Rated voltage up to 1500 VDC on app-fit trend with lower temperature rising (up to 35 degrees).
• Patented Diabolo technology brings more reliable high-current connection.
• Quick-lock and instant release mechanism brings simple plug-and-play to the field.

• Space saving Hybrid power and signal miniaturization design. Benefit for compact arrangement of battery pack size.
• Floating Design: advance steering and Floating designs balance and allow tolerance margins in blind inserted systems.
• Operation efficiency improvement: Stamping contact Design, greatly improve the line efficiency and crimping consistency.

• Power dissipation capability up to 500 W
• Customs designs, windings, terminations, and mountings available
• Availability of Low-Inductance versions

• High Density Connector: Signals up to 7.5 A
• 8-63 positions
• Accepts Size 20 DF/DM contacts

• Combination Standard and Power Density Connector: signals up to 25 A, power up to 47 A
• 13-22 positions
• Accepts Size 16 Multimate contacts and Type XII power contacts in same housing

• High-performance data and power transmission
• Utilizes the same contact system and the same termination tooling as CPC, ensuring a low-applied cost
• Designed for panel, free hanging or PC board applications

• High degree of robustness and reliability
• High wipe lenght of 2.5 mm
• Comprehensive portfolio

• DC rate up to 1.000 V
• Secure colour and mechanical coding
• Primary and secondary locking system

• High current rating up to 9 A (1 A Flexfoil)
• Double IDC with integrated cord grip
• Integrated electrical CPA
• Wire-to-Board Flexfoil with integrated strain relief
• High temperature up to 150°C

• 3-point box contact
• Robust termination and vibration resistant
• Clear mating sound
• Current up to 15 A

MicroSpeed Power Module (Current rating up to 18A/pin)
• High design robustness: blind mate versions available
• Contact technology can be SMT or THR
• Shielded board-to-board connector

Power Element
• Power distribution up to 360 A
• Press-Fit and SMD termination available
• Shock and vibration proof

Power Taps
• High current rating up to 40 A
• Various of thread sizes (English and metric)
• High flexibility of cable connection

• Hermetically sealed with ceramic technology
• Built-in PWM economizer, with 1.7 W hold power
• 50 A to 500 A carry currents capability versions
• Maximum DC breaking voltage at 1000 VDC
• Versions to switch polarized or bi-directional loads
• CCC, CE, UL & TÜV approved

• General Purpose Power relay, available in Screw and push in terminals
• UL and VDE certified
• Switching relay for automation panels

• Most compact CO relay, 5/6 A rated current with 1 form C (CO) contacts
• Available in Bistable version as well
• Ambient temperature up to 85°C
• Max height 10.0 mm
• Designed for Smart home automation controls, Temperature & lighting controls, Timer monitoring

• Various 3 to 10 A rated versions in compact size
• 1 Form A / 1 N/O contact version
• Meets 4 kV dielectric between coil and contacts
• Ambient temperature up to 85°C
• Meets UL TV-5 ratings (OJT)
• Designed for White Goods applications, HVAC, Industrial Controls, Small PLCs

• Compact 10 A, with 1 form C (CO) or 1 form A (NO) contact
• Ambient temperature up to 85°C
• Flux proof or sealed type versions available.
• 15 A switching capacity
• 6kV dielectric strength type available
• Good for use in smart appliances, HVAC applications

• Common-mode Chokes mitigation up to 100 A – EMI / EMC
• 3 phase + N or DC EMI mitigation
• Rated currents 16 A to 50 A AC or up to 100 A DC
• Horizontal and vertical configurations
• Economy version with ferrite core
• Performance version with nanocrystalline core

• Design acc. to EV – Charging safety standards
• Fulfills the requirements in IEC/EN 61851-23 and UL 2202
• Multiple performance options

• 30 A Power PCB relay for HVAC, appliance and industrial control applications. 40 A UL rating available.
• Smallest in class
• Meets IEC 61810-1 for reinforced insulation
• Quick connect terminals available
• WG Versions available

• Switch heavy industrial loads with confidence, up to 40 A.
• Save space and ensure reliability with a compact, and robust design.
• Power solutions across HVAC, energy, and automation with one versatile relay.

• High-capacity switching of 16 A at 250 VAC, 1 NO or CO contacts for compressors, fans, pumps, and heating elements used in heat pumps, air conditioners with long lifetime.
• Eco-friendly, explosion-proof design supports A3-class flammable refrigerants for next-gen cooling systems and compliance with global climate regulations.
• Designed for long electrical life and excellent inrush handling, the relay delivers consistent performance in demanding compressor and heating duty cycles.

• Ventilation cable glands: 2 in 1 product, cable gland and ventilation plug
• Balances pressure differences between inner housing and the outside environment
• Polyamide and brass material

• Time saving and easy configuration thanks to ready-to be used pre-equipped boxes (pre-mounted & premarked terminal blocks assemblies and pre-installed cable glands.
• Screw clamp or PI-Spring terminal block assemblies with 6 or 12 connections and motor application.

• Identify all types of wires, cables in Industrial and Harsh environments.
• Heat shrink tubing (ladder or continuous tube) available in multiple grades (up to 6), sizes and colors (up to 8).
• Tags available in multiple grades (up to 4), sizes and colors (white, yellow).

• Connection, grouping, and splitting for inverters from 80 A up to 520 A
• Compact Blocks in different color combination 50 Sqmm-300 Sqmm size.
• Distribution Block DBL 500-F Specifically to showcase flat bus bar entry models essential for EV charging cabinet.

• DBLK Power Line – PI Spring technology for power distribution
• Ranging from 75 Amps to 125 Amps with global certification package and toolless usage.

• For 10x38 mm, class CC and 10x85 mm photovoltaic fuses
• For 1, 2, or 3 poles, including neutral configuration
• Up to 32 A, 690 VAC/DC and 1500 VDC for 10x85 mm PV fuses

Anti-Vandal:
• On/Off locking & Momentary style available
• Various LED & Icon options available
• IP67 sealed outside the panel

Emergency Switch:
• NO & NC contact modules configurations, Illuminated version available
• IP65 sealed outside the panel

DIP Switches
• 4 positions
• Extended actuators
• No process seal required

Tactile Switches
• 6x6 standard size
• Various heights available
• Various forces available

• Hybrid power & signal
• 4 power contacts type (2.5, 16, 35, 50mm2)
• Signal contacts gold plated (5 A/50 V)
• Rated current 150-200 A/ Rated Voltage 1000 V
• Floating system to help the mating phase

• Connection and mounting ergonomics
• Common accessories to all technologies
• Qualified for worldwide applications and harsh environments

• Custom cable assemblies
• Customized designs, created through Engineering-to-Engineering contact
• Tailored to meet the requirements of a specific application
• Maximized TE content to ensure the most cost-effective solution

• Broad portfolio of connectors and cord sets
• Panel, PCB, Cable and FI connectors
• Solutions for power and sensor, bus and Ethernet communication
