Push-In PCB Terminal Blocks: Time Saving Connectors

Push-In PCB Terminal Blocks: Time Saving Connectors-CAT-124-T
TE's PCB TB connectors offer a tool-less wire insertion method, reducing installation labour time. The design of the PCB terminal blocks in 2.5 mm, 3.5 mm, and 3.81 mm pitches consists of two-piece plug connectors with mating straight and right-angle shrouded headers. They are Specifically designed for high-density signal and power applications in control systems.
More Less

Product Features

  • Number of Positions : 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18, 20, 22, 24, 28, 32, 34, 40, 48

  • Terminal Block Connector Type : Header, Plug

  • Connector System : Wire-to-Board

  • Centerline (Pitch) (mm): 2.5, 3.5, 3.81

  • Centerline (Pitch) (in): .137, .15, .98

  • Number of Rows : 1, 2

Available from

LADD Inc
Overview

Related Materials

heat pump and air conditioning component solutions for HVAC

Application

Innovative HVAC Component Solutions

Upgrade your Residential HVAC system with our durable and sealed components. Explore solutions for compressor, blower motor, control board and solenoid valves.

Motion Control

TE Connectivity’s broad electromechanical and electronic product portfolio for motion control devices covers your needs in a wide variety of production environments.

Datasheet(English)
PUSH-IN PCB TERMINAL BLOCK CONNECTORS

TE Connectivity (TE) is expanding its terminal block connectors portfolio with push-in clamp termination PCB connectors to provide for virtually tool-less wire insertion of ferruled and unferruled wires. Comparing this to a standard screw-clamp termination, installation labour time can be reduced by up to 80%, resulting in significant cost savings. The design of the PCB terminal blocks in 2.5 mm, 3.5 mm, and 3.81 mm pitches consist of two-piece plug connectors with mating straight and right-angle shrouded headers. This product range is intended for high-density signal and power applications in control systems.

Servo Motors and Drive

Servo Motors and Drive

Interested in learning more about Variable Speed Drives or Servo Motors & Drives? Need a sample or a customer drawing? TE has a breadth of products to solve your application demands. Simply complete the form and we will connect with you soon!

 CONNECT WITH US
Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

  • Wire Protection  Without

  • Header Type  Fully Shrouded

  • Terminal Block Connector Type  Header, Plug

  • Connector System  Wire-to-Board

  • Connector & Contact Terminates To  Printed Circuit Board, Wire & Cable

Configuration Features

  • Number of Positions  2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18, 20, 22, 24, 28, 32, 34, 40, 48

  • Number of Rows  1, 2

  • Wire Entry Angle  180°

  • Wire Entry Location  Top

Electrical Characteristics

  • Operating Voltage (VAC) 150, 300

Body Features

  • Primary Product Color  Black, Green

  • Lever Color  Orange

  • Product Orientation  Vertical, Horizontal

Contact Features

  • Contact Underplating Material  Nickel

  • Contact Mating Area Plating Material  Tin (Sn)

  • Contact Base Material  Copper Alloy, Phosphor Bronze

  • Contact Current Rating (Max) (A) 4, 8

Termination Features

  • Termination Post & Tail Length (mm) 2, 3.5, 3.8

  • Termination Post & Tail Length (in) .079, .137, .149

  • Termination Method to PCB  Through Hole - Solder

  • Termination Method to Wire & Cable  Push-in

Mechanical Attachment

  • Connector Mounting Type  Board Mount

Housing Features

  • Housing Material  LCP, PA 66

  • Centerline (Pitch) (mm) 2.5, 3.5, 3.81

  • Centerline (Pitch) (in) .137, .15, .98

Dimensions

  • Wire Size (AWG) 24 – 16, 28 – 16, 28 – 20

  • Wire Size (mm²) .08 – 1.3, .08 – .52, .2 – 1.3

Usage Conditions

  • Operating Temperature Range  -40 – 115 °C [ -40 – 239 °F ]

Operation/Application

  • Circuit Application  Power & Signal

Industry Standards

  • Compatible With Agency/Standards Products  RU (UL Component Program)

Packaging Features

  • Packaging Method  Box

Reference Number

  • TE Internal Number CAT-124-T
