Design Flexibility for High Power Systems

Universal MATE-N-LOK connectors are the industry standard power connector for a variety of applications, including appliances, industrial machinery, and building equipment. Engineers value these connectors for design versatility and TE continues to introduce innovative Universal MATE-N-LOK products to solve the latest power design challenges. The connector system features a variety of specialized connectors, including flanged, bulkhead, sealed, and twist and lock options, that can be used in wire-to-wire, wire-to-board, and panel mount designs. Universal MATE-N-LOK housings feature polarization, positive locking, and rear cavity identification for easy, error resistant assembly. Housings accept both pin and socket contacts and these contacts can be intermixed in the same housing.

umnl-connectors-features
MATE-N-LOK Connectors
Centerline (in) mm
Max Current Rating (A)
Voltage Rating
Wire Size (AWG)
Wire Insulation Dia. (in) mm
Positions
Sealed Version
UL 94 Rating
Agency Approvals
Operating Temperature (°C)

(.250) 6.35

19

600V AC/DC

30-10

(.200) 5.08

1-15

Yes

V-0 & V-2

UL, CSA, VDE

 -55° to +125°

(.250) 6.35

19

600V AC/DC

30-10

(.200) 5.08

2-15

No

V-0

UL, CSA, VDE

 -55° to +105°

(.118) 3.00

5

250V AC

30-20

(.060) 1.52

2-24

No

V-0

UL, CSA, VDE

-40° to +105°

(.163) 4.14

9.5

600V AC/DC

30-16

(.126) 3.20

1-24

Yes

V-0 & V-2

UL, CSA,

VDE (250 V Max.)

-55° to +105°

(.163) 4.14

10.5

600V AC/DC

30-16

(.126) 3.20

2-24

No

V-0 & V-2

UL, CSA, VDE

-55° to +105°

(.200) 5.08

19

250V AC

30-14

(.130) 3.30

1-16

No

V-2

UL, CSA

-55° to +105°

(.240) 6.10

28

600V AC/DC

20-10

(.180) 4.57

2-9

No

V-2

UL, CSA

-55° to +105°

(.390) 9.91

32.5

 600V AC

20-10

(.185) 4.70

3-4

No

V-2

UL

-55° to +105°

This product table can only be viewed on desktop.

grey-bar
Sealed Connectors That Solve For Complex Design Needs
Engineered for Durability, Protection, and Versatility

TE’s sealed connector portfolio is designed to meet the protection and durability demands engineers face in tackling today’s complex design challenges. Our connectors also address key industry needs like ergonomics, miniaturization, simplification, and safety, ensuring they excel across a wide range of applications.

Sealed Connectors That Solve For Complex Design Needs
Engineered for Durability, Protection, and Versatility

TE’s sealed connector portfolio is designed to meet the protection and durability demands engineers face in tackling today’s complex design challenges. Our connectors also address key industry needs like ergonomics, miniaturization, simplification, and safety, ensuring they excel across a wide range of applications.

Micro MATE-N-LOK Blind Mate Connector
Enhancing Wire Harness Assembly Efficiency

Micro MATE-N-LOK blind mate connector improves the efficiency of wire harness assembly by reducing the need for visual checks and simplifying connector alignment. It features a lead-in funnel structure that provides a large surface area for connector alignment, making it easier for operators, installers, and end-users to cycle the connection.

Micro MATE-N-LOK Blind Mate Connector
Enhancing Wire Harness Assembly Efficiency

Micro MATE-N-LOK blind mate connector improves the efficiency of wire harness assembly by reducing the need for visual checks and simplifying connector alignment. It features a lead-in funnel structure that provides a large surface area for connector alignment, making it easier for operators, installers, and end-users to cycle the connection.
