Insulated Terminals for Simplified Assembly

Ultra-Fast fully insulated FASTON receptacles and tabs feature a pre-insulated crimp terminal for safe, easy assembly and lower applied costs. The Ultra-Fast terminals create dependable electrical connections with a closed barrel crimp that has comparable electromechanical performance to open barrel terminals and a receptacle with multiple points of contact for reduced interface resistance. The insulated terminals are easy to manually assemble with an ergonomic low insertion force (LIF) design and no need for hazardous chemically expanded or heat shrink tubing. When using automated termination, terminal crimping and insulation are completed in a single stroke, eliminating secondary insulation steps and allowing for applied cost savings.

ultra fast fully insulated faston receptacles and tabs

Product Features

Tab Width (in.) .110, .125, .187, .205, .250 Orientations Straight & Flag
Tab Thickness (in.) .016-.032 Crimp Types D Crimp
Wire Size (AWG) 26-10 Materials / Plating Base: Brass, Phos. Bronze
Plating: Tin
Max Continuous Current (A) 24 Pre-insulation Available Yes
Max Operating Temperature (°C) 105 Agency Approval(s) UL & CSA
Receptacle to Tab Mating Force (N) ≤75.6 Insulation Flammability Ratings UL 94 V-2
