19mm High Accuracy Pressure Capsule | 82H Model

Part of the 8XH series, the 82H model high-accuracy pressure capsule features a 19mm diameter module and a standard recessed diaphragm with an O-ring mount.

More Less

Connect with Us

Product Features

Pressure (bar): .138 | .345 | 1 | 1.034 | 2 | 2.068 | 3.447 | 5 | 6.895 | 10 | 10.342 | 34.474 | 100
Pressure (psi): 2 | 5 | 14.5 | 15 | 29 | 30 | 50 | 72.5 | 100 | 145 | 150 | 500 | 1450
Pressure Sensor Type : Analog Pressure Sensor Modules | Digital Pressure Sensor
Pressure Type : Absolute | Gauge | Vacuum Gauge
Output Signal Details : 0.5 – 4.5 VDC | 24 bit I2C
Supply Voltage Range (V): 2.7 – 3.6 | 4.75 – 5.25

Available from

Product	TE Part #	Documents	Pressure	Pressure Sensor Type	Pressure Type	Output Signal Details	Supply Voltage Range	Operating Temperature Range
PRESSURE CAPSULE, 82HD-100BA-RS	20032987-11	3D PDF	100 bar	Digital Pressure Sensor	Absolute	24 bit I2C	2.7 – 3.6 V	-20 – 105 °C
PRESSURE CAPSULE, 82HD-150PG-RS	20032987-06	3D PDF	10.342 bar	Digital Pressure Sensor	Gauge	24 bit I2C	2.7 – 3.6 V	-20 – 105 °C
PRESSURE CAPSULE, 82HD-010BA-PS	20032987-08	3D PDF	10 bar	Digital Pressure Sensor	Absolute	24 bit I2C	2.7 – 3.6 V	-40 – 125 °C
PRESSURE CAPSULE, 82HA-002BA-PS	20032541-02	3D PDF	2 bar	Analog Pressure Sensor Modules	Absolute	0.5 – 4.5 VDC	4.75 – 5.25 V	-40 – 125 °C
PRESSURE CAPSULE, 82HD-030PA-RS	20032987-05	3D PDF	2.068 bar	Digital Pressure Sensor	Absolute	24 bit I2C	2.7 – 3.6 V	-20 – 105 °C
PRESSURE CAPSULE, 82HD-005PG-PS	20032987-09	3D PDF	.345 bar	Digital Pressure Sensor	Gauge	24 bit I2C	2.7 – 3.6 V	-20 – 70 °C
PRESSURE CAPSULE, 82HA-001BA-PS	20032541-01	3D PDF	1 bar	Analog Pressure Sensor Modules	Absolute	0.5 – 4.5 VDC	4.75 – 5.25 V	-40 – 125 °C
PRESSURE CAPSULE, 82HA-100PG-RTS	20032541-03	3D PDF	6.895 bar	Analog Pressure Sensor Modules	Gauge	0.5 – 4.5 VDC	4.75 – 5.25 V	-20 – 105 °C
PRESSURE CAPSULE, 82HD-050PV-PS	20032987-03	3D PDF	3.447 bar	Digital Pressure Sensor	Vacuum Gauge	24 bit I2C	2.7 – 3.6 V	-40 – 125 °C
PRESSURE CAPSULE, 82HD-500PG-RS	20032987-04	3D PDF	34.474 bar	Digital Pressure Sensor	Gauge	24 bit I2C	2.7 – 3.6 V	-20 – 105 °C
PRESSURE CAPSULE, 82HD-001BG-RTS	20032987-10	3D PDF	1 bar	Digital Pressure Sensor	Gauge	24 bit I2C	2.7 – 3.6 V	-20 – 105 °C
PRESSURE CAPSULE, 82HD-100PV-PS	20032987-07	3D PDF	6.895 bar	Digital Pressure Sensor	Vacuum Gauge	24 bit I2C	2.7 – 3.6 V	-40 – 125 °C
PRESSURE CAPSULE, 82HD-015PV-PS	20032987-00	3D PDF	1.034 bar	Digital Pressure Sensor	Vacuum Gauge	24 bit I2C	2.7 – 3.6 V	-40 – 125 °C
PRESSURE CAPSULE, 82HD-005BA-PS	20032987-02	3D PDF	5 bar	Digital Pressure Sensor	Absolute	24 bit I2C	2.7 – 3.6 V	-40 – 125 °C
PRESSURE CAPSULE, 82HD-002BA-PS	20032987-01	3D PDF	2 bar	Digital Pressure Sensor	Absolute	24 bit I2C	2.7 – 3.6 V	-40 – 125 °C

Overview

Features

O-ring mount
316L stainless steel
-20°C to +85°C compensated temperature range
±0.1% FS pressure accuracy
±0.3% FS Total Error Band
Low power consumption
ISO packages, factory calibrated

Applications

PDF

8XH Series Pressure Capsule Product Postcard

PDF

8XH Series Pressure Capsule Solution Guide

PDF

8XH Series Pressure Capsule Flyer

Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

Pressure Sensor Type Analog Pressure Sensor Modules | Digital Pressure Sensor
Pressure Type Absolute | Gauge | Vacuum Gauge
Sensor Package O-Ring Mount

Configuration Features

Electrical Connection 6" Ribbon Cable | Header 4 Pin

Electrical Characteristics

Supply Voltage Range (V) 2.7 – 3.6 | 4.75 – 5.25

Dimensions

Product Diameter (in) .747
Product Height (in) .415 | .515

Usage Conditions

Total Error Band ± (%) .3
Pressure (bar) .138 | .345 | 1 | 1.034 | 2 | 2.068 | 3.447 | 5 | 6.895 | 10 | 10.342 | 34.474 | 100
Pressure (psi) 2 | 5 | 14.5 | 15 | 29 | 30 | 50 | 72.5 | 100 | 145 | 150 | 500 | 1450
Operating Temperature Range (°C) -40 – 125 | -20 – 70 | -20 – 105
Operating Temperature Range (°F) -40 – 257 | -4 – 158 | -4 – 221

Operation/Application

Proof Pressure Range 3X Rated
Output Interface Analog Voltage | I²C
Pressure Accuracy ± (%) .1
Output Signal Details 0.5 – 4.5 VDC | 24 bit I2C

Other

Sensor Options 316L Stainless Steel
Non-Linearity ± (%) .1
Port Fitting O-Ring Radial Seal
