CAT-AN862-L6267A Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. SHARK FIN MIMO ANTENNA CAT-AN862-L6267A
active
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type SMA Plug
  • Number of Ports 2
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol GNSS
  • Band Type 6 band
  • Impedance 50
  • Active Antenna Yes
  • VSWR (Max) <2:1
  • Gain (Max) 5
  • Frequency Band 1562 – 1612
  • Product Weight 260
  • Mounts To Vehicle Rooftop
  • Mounting Retention Type Adhesive
  • Polarization Right Hand Circular
  • Region Global
  • Cable Insulation Diameter (Max) 2.8
  • Cable Length 300
  • Product Length 170
  • Product Width 60
  • Product Height 50
  • Application by Region GPS - Global - 1565 – 1585 MHz
  • Wireless Application GPS
  • Packaging Method Bag/Box
CAT-R131-R672 Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. RAIL ROOFTOP MIMO LTE ANTENNA CAT-R131-R672
active
EN45545 IEC 50155 IEC 61076-2-101 IEC 61373 IP67
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type N-Type Socket
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol GNSS
  • Band Type Triple Band
  • Active Antenna No
  • Frequency Band 1710 – 6000
  • Mounts To Rail Rooftop
  • Mounting Retention Type 4-Hole Mount
  • Application by Region LTE All Band - 1710 – 2700 MHz
  • Wireless Application GPS
CAT-R131-R672A Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. RAIL ROOFTOP SISO LTE ANTENNA CAT-R131-R672A
active
EN45545 IEC 50155 IEC 61076-2-101 IEC 61373 IP67
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type N-Type Socket
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol GPS\GNSS
  • Band Type Triple Band
  • Active Antenna No
  • Frequency Band 1710 – 6000
  • Mounts To Rail Rooftop
  • Mounting Retention Type 4-Hole Mount
  • Wireless Application GPS
CAT-R131-L6267 Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. LIGHT TRANSIT MIMO LTE ANTENNA CAT-R131-L6267
active
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type SMA Plug
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol LTE MIMO
  • Band Type Triple Band
  • Active Antenna No
  • Frequency Band 1710 – 2700
  • Mounts To Vehicle Rooftop
  • Mounting Retention Type Adhesive
  • Cable Length 300
  • Product Width 176
  • Product Height 62
  • Wireless Application GPS
  • Packaging Method Bag/Box
CAT-R131-AN862F Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. Puck Antenna: Low Profile Multi-Function CAT-R131-AN862F
active
  • Antenna Connection Type FAKRA
  • Antenna Connector Type FAKRA D
  • Number of Ports 1
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol GNSS
  • Impedance 50
  • Active Antenna No
  • VSWR (Max) <2.5:1
  • Gain (Max) 4
  • Frequency Band 1562 – 1612
  • Mounts To Panel
  • Mounting Retention Type Panel Mount
  • Polarization Vertical Linear
  • Region Global
  • Cable Insulation Diameter (Max) 2.8
  • Product Diameter 80
  • Cable Length 1000
  • Product Height 22.5
  • Application by Region CDMA - Americas - 1850 – 1990 MHz
  • Wireless Standard 802.11 a/g/n/ac & Wi-Fi
  • Wireless Application CDMA 1900
  • Packaging Method Bag/Box
  • Precision Level Standard
CAT-R131-T673 Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. M2M/IOT MIMO LTE ANTENNA CAT-R131-T673
active
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type SMA Plug
  • Number of Ports 2
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol GNSS
  • Band Type Triple Band
  • Impedance 50
  • Active Antenna No
  • Gain (Max) 4.5
  • Frequency Band 1562 – 1612
  • Product Weight 337
  • Mounts To Panel
  • Mounting Retention Type Adhesive
  • Polarization Right Hand Circular
  • Region Global
  • Cable Insulation Diameter (Max) 2.8
  • Cable Length 3000
  • Product Length 150
  • Product Width 45
  • Product Height 49
  • Wireless Standard GPS
  • Wireless Application GPS
  • Packaging Method Bag/Box
CAT-R131-AN862I Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. Vehicle Antenna: Low Profile, IoT CAT-R131-AN862I
active
  • Antenna Connection Type FAKRA
  • Antenna Connector Type FAKRA D
  • Number of Ports 1
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol LTE / UMTS / US DUAL / EU TRIVAND / WCDMA
  • Impedance 50
  • Active Antenna No
  • VSWR (Max) <2.5:1
  • Gain (Max) 6
  • Frequency Band 1710 – 3800
  • Mounts To Panel
  • Mounting Retention Type Panel Mount
  • Polarization Vertical Linear
  • Region Global
  • Cable Insulation Diameter (Max) 2.8
  • Product Diameter 116
  • Cable Length 1000
  • Product Height 49.5
  • Application by Region CDMA - Americas - 1850 – 1990 MHz
  • Wireless Standard 802.11 a/g/n/ac & Wi-Fi
  • Wireless Application CDMA 1900
  • Packaging Method Bag/Box
  • Precision Level Standard
CAT-R131-ST242 Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. PUBLIC SAFETY MIMO LTE ANTENNA CAT-R131-ST242
active
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type SMA Plug
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol GNSS
  • Band Type 6 band
  • Active Antenna Yes
  • Frequency Band 2400 – 2485
  • Product Weight 262.7
  • Mounts To Vehicle Rooftop
  • Mounting Retention Type Adhesive
  • Cable Length 300
  • Product Length 172
  • Product Width 61
  • Product Height 51
  • Wireless Application GPS
  • Packaging Method Bag/Box
CAT-R131-AN862 Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. Cellular Antenna: High Gain CAT-R131-AN862
active
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type N-Type Socket
  • Number of Ports 2
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol LTE / UMTS / US DUAL / EU TRIVAND / WCDMA
  • Impedance 50
  • Active Antenna No
  • VSWR (Max) < 2.0:1
  • Gain (Max) 3.9
  • Frequency Band 1710 – 2700
  • Product Weight 1300
  • Mounts To Wall
  • Mounting Retention Type Bracket
  • Polarization Vertical Linear
  • Region Global
  • Cable Insulation Diameter (Max) 5
  • Cable Length 300
  • Product Length 19.94
  • Product Width 180
  • Product Height 230
  • Application by Region CDMA - Americas - 1850 – 1990 MHz
  • Wireless Standard EU Cellular
  • Wireless Application 5G
  • Packaging Method Bag/Box
  • Precision Level Standard
951-016-141 Antennas  1
PRODUCT
  1. Antennas
  2. Antennas
  1. TGN 3847 RD S - FMEf SMBf 0,2 951-016-141
active
  • Antenna Connection Type Cable Assembly
  • Antenna Connector Type FME
  • Number of Ports 2
  • Antenna Style External
  • Antenna Type Enclosure
  • Antenna Protocol GNSS
  • Band Type Wideband
  • Impedance 50
  • Active Antenna Yes
  • VSWR (Max) <1.65
  • Gain (Max) 2
  • Frequency Band 1563 – 1610
  • Product Weight 180
  • Mounts To Conductive Surface
  • Mounting Retention Type Screw Mount
  • Polarization RHCP
  • Region Global
  • Cable Insulation Diameter (Max) 2.5
  • Cable Length 150
  • Product Length 95
  • Product Width 57
  • Product Height 40
  • Application by Region GNSS - Global - L1 - 1575.4
  • Wireless Standard L1/GPS Glonass Galileo
  • Wireless Application Glonass
  • Packaging Method Bag/Carton
  • Precision Level Standard
