- Interface Analog
- Voltage Supply 8 – 30
- Interface Analog .5 – 4.5
- Tilt Sensor & Inclinometer Mounting Horizontal
- Measurement Ranges up to +/- 25
- Dimension up to 70
- Tilt Sensor & Inclinometer Accuracy up to +/- .3
- Resolution up to +/- .01
- Measurement Principle MEMS
- Operating Temperature Range -40 – 85
- Tilt Sensor & Inclinometer Package Plastic Housing
- Measurement Axes Dual Axis
- Protection Class IP 67
- Connection Connector TE/AMP

- Interface Digital
- Voltage Supply 5
- Tilt Sensor & Inclinometer Mounting Horizontal
- Measurement Ranges up to +/- 90
- Dimension up to 70
- Tilt Sensor & Inclinometer Accuracy up to +/- .5
- Resolution up to +/- .01
- Measurement Principle MEMS
- Operating Temperature Range -40 – 85
- Tilt Sensor & Inclinometer Package Plastic Housing
- Measurement Axes Dual Axis
- Protection Class IP 67
- Interface Digital RS232
- Connection Connector USB

- Float SG .85
- Liquid Level Switch Mounting Side Entry
- Liquid Level Switch Material Glass Filled Nylon 6.6
- Seal Material Nitrile
- Contact Form A
- Liquid Level Switch Cable Length .5
- Medium/Liquid Alcohol
- Fitting 1/2 NPT

- Operating Temperature Range -40 – 150
- Operating Range Density from 0.65 to 1.5 g/cc
- Fluid Property Sensor Product Type Oil Property Sensors
- Package Fully Integrated, Stand-Alone Module Combines Sensor & Processing Electronics For In-Situ Monitoring

- Float SG .68
- Liquid Level Switch Mounting Bottom Entry
- Liquid Level Switch Material Glass Filled Nylon 6.6
- Seal Material Nitrile
- Contact Form A
- Liquid Level Switch Cable Length .5
- Medium/Liquid Alcohol
- Fitting M16 External

- Humidity Sensor Component Product Type RHT
- Humidity Sensor Component Sensor Type Analog
- Supply Voltage (Peak) 5.5
- Current Consumption .76
- Humidity Operating Range 0 – 100
- Operating Temperature Range -40 – 125

- Humidity Sensor Assembly Product Type RHTP
- Humidity Sensor Assembly Sensor Type Digital
- Supply Voltage (Peak) 5.5
- Current Consumption 10
- Transmit Rate 100
- Baud Rate 250
- Operating Temperature Range -40 – 105
- Humidity Measuring Range 0 – 100
- Humidity Sensor Assembly Accuracy ±3
- Pressure (Max) 130
- Response Time 5

- Interface Digital
- Voltage Supply 5
- Tilt Sensor & Inclinometer Mounting Horizontal
- Measurement Ranges up to +/- 180
- Dimension up to 70
- Tilt Sensor & Inclinometer Accuracy up to +/- .5
- Resolution up to +/- .01
- Measurement Principle MEMS
- Operating Temperature Range -40 – 85
- Tilt Sensor & Inclinometer Package Plastic Housing
- Measurement Axes Single Axis
- Protection Class IP 67
- Interface Digital RS232
- Connection Connector USB

- Humidity Sensor Assembly Product Type RHT
- Humidity Sensor Assembly Sensor Type Analog
- Supply Voltage (Peak) 20
- Nominal Output @55%RH (at 5 VDC) 1.515
- Current Consumption 1
- Output Impedance 50
- Nominal Resistance @25°C 10
- Nominal Resistance Tolerance @25°C 1
- Operating Temperature Range -40 – 110
- Humidity Measuring Range 0 – 100
- Humidity Sensor Assembly Accuracy ±3
- Temperature Coefficient -.05
- Sensitivity 18
- Response Time 10
- β-Value B25/50 3380

- Float SG .8
- Electrical Connection Delphi
- Liquid Level Switch Mounting Side Entry
- Liquid Level Switch Material Acetal and Foamed Polypropylene
- Seal Material EPDM
- Contact Form A
- Medium/Liquid Water
- Fitting Push Fit Grommet

Application
Industrial and Commercial Transportation Sensors
TE Connectivity (TE) sensors provide data under harsh conditions with accuracy and reliability.
TE Connectivity (TE) pressure, level, temperature, urea quality, and humidity sensors are recognized and validated solutions in emission/exhaust control systems to comply with Final Tier 4 and Euro VI stage C regulations. Additionally, TE designs and manufactures a range of linear position, level, humidity, temperature, speed, and pressure sensors for chassis and transmission applications and has developed innovative combination sensors for cost effective and efficient control. Our sensors are designed and manufactured to exacting specifications, often on a custom basis. Together with our customers, we are working to solve today's biggest application challenges in new and creative ways.

Application
Industrial and Commercial Transportation Sensors
TE Connectivity (TE) sensors provide data under harsh conditions with accuracy and reliability.
TE Connectivity (TE) pressure, level, temperature, urea quality, and humidity sensors are recognized and validated solutions in emission/exhaust control systems to comply with Final Tier 4 and Euro VI stage C regulations. Additionally, TE designs and manufactures a range of linear position, level, humidity, temperature, speed, and pressure sensors for chassis and transmission applications and has developed innovative combination sensors for cost effective and efficient control. Our sensors are designed and manufactured to exacting specifications, often on a custom basis. Together with our customers, we are working to solve today's biggest application challenges in new and creative ways.
