Features

Please review product documents or contact us for the latest agency approval information.

Electrical Characteristics

  • Short Circuit Current Rating (kA) 100

  • Operating Voltage (Max) (VAC) 480

  • Current Rating (Max) (A) 2.3, 3.1, 5.9, 10, 13, 18, 26, 32, 38, 45, 60, 75, 90, 110, 145, 180, 200, 250, 300, 400, 480, 630, 710, 800, 1000

Body Features

  • Product Weight (g) 1050, 1400, 2000, 4800, 5100, 6200, 8900, 11200, 11400, 12800, 17500, 20300, 23600, 27100, 51000, 52000, 54000, 69000, 90000, 118000, 136000, 164000, 200000, 239000

  • Product Weight (oz) 37.03, 49.38, 70.54, 169.31, 179.89, 218.69, 313.93, 395.06, 402.12, 451.5, 617.29, 716.06, 832.46, 955.92, 1798.97, 1834.24, 1904.79, 2433.9, 3174.65, 4162.32, 4797.25, 5784.92, 7054.79, 8430.47

  • Product Weight (g) 1050, 1400, 2000, 4800, 5100, 6200, 8900, 11200, 11400, 12800, 17500, 20300, 23600, 27100, 51000, 52000, 54000, 69000, 90000, 118000, 136000, 164000, 200000, 239000

Mechanical Attachment

  • Product Mount Type  Floor Mount

Dimensions

  • Product Width (mm) 63, 69, 72, 84.5, 95, 139, 142, 149, 169, 177, 178, 183, 223, 226, 239, 263, 303, 308, 313, 353, 355, 384

  • Product Width (in) 2.48, 2.71, 2.83, 3.32, 3.74, 5.47, 5.59, 5.86, 6.65, 6.96, 7, 7.2, 8.77, 8.89, 9.4, 10.35, 11.92, 12.12, 12.32, 13.89, 13.97, 15.11

  • Product Length (mm) 120, 150, 195, 220, 240, 265, 290, 420

  • Product Length (in) 4.72, 5.9, 7.67, 8.66, 9.44, 10.43, 11.41, 16.53

  • Product Height (mm) 118, 137, 157, 159, 160, 178, 183, 197, 198, 218, 234, 338, 389, 403, 498, 594, 693, 722, 821, 1013

  • Product Height (in) 4.64, 5.39, 6.18, 6.25, 6.29, 7, 7.2, 7.75, 7.79, 8.58, 9.21, 13.3, 15.31, 15.86, 19.6, 23.38, 27.28, 28.42, 32.32, 39.88

Usage Conditions

  • Motor Cable Length (Max)  100 m [ 328.08 ft ]

Operation/Application

  • Operating Altitude (Max) (m) 2000

  • Level of Output Filtering  DV/DT Reduction By Factor 10

  • Motor Frequency (Hz) 200

Industry Standards

  • Certified To  EN 60076-6, EN 61558-2-20

  • Pollution Degree  PD3

  • IP Rating  IP00

  • UL Flammability Rating  UL 94V-2

Reference Number

  • TE Internal Number CAT-PE4-R5420
