Power Entry Module with EMC Filter FN390, Versatile Filtered Power Entry Module

FN380-CAT-PC9-F380
The FN390 delivers up to 10 A of filtered power input with support for one or two fuses (ø6.3 × 32 mm or ø5 × 20 mm). It includes a 2-pole rocker switch, integrated voltage selector, and optional earth line choke (E type), making it a reliable choice for versatile general-purpose applications.
More Less

Product Features

  • Current Rating (Max) (A): 2, 4, 6

  • Filtering Requirements : Unfiltered

  • Leakage Current (Max) (250VAC, 50Hz) (µA): 2, 373

  • Output Termination Type : FASTON

  • Pollution Degree : PD2

Available from

LADD Inc
Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

  • Filter Switch Type  DPST

  • Level Of Filtering  Inductor & Capacitor

  • Filtering Requirements  Unfiltered

  • Output Termination Type  FASTON

Configuration Features

  • Fuse Options  Dual, Single

Electrical Characteristics

  • Inductance L1 (µH) .18, .3, .5, .7, .8, 2

  • Overvoltage Category  II

  • Capacitance Cx1  4.7, 47

  • Capacitance Cy1  2.2

  • Current Rating (Max) (A) 2, 4, 6

  • Leakage Current (Max) (250VAC, 50Hz) (µA) 2, 373

Body Features

  • Product Weight (g) 55, 60, 65, 70

  • Product Weight (oz) 1.94, 2.11, 2.29, 2.46

Dimensions

  • Product Width (mm) 32, 50, 58

  • Product Width (in) 1.25, 1.96, 2.28

  • Product Length (mm) 32, 50, 56.5, 66.5

  • Product Length (in) 1.25, 1.96, 2.22, 2.61

  • Product Height (mm) 56.5, 58

  • Product Height (in) 2.22, 2.28

Operation/Application

  • Cooling Method  Natural Convection

Industry Standards

  • Certified To  CSA 22.2 No. 8 1986, IEC/EN 60939, UL 1283

  • Pollution Degree  PD2

  • IP Rating  IP40

  • UL Flammability Rating  UL 94V-2

Reference Number

  • TE Internal Number CAT-PC9-F380
