Product Type Features
-
Filtering Requirements
Unfiltered
-
Input Termination Type
Busbar
-
Output Termination Type
Busbar
Configuration Features
-
Wiring Configuration
Three Phase
Electrical Characteristics
-
Overvoltage Category
II
-
Current Rating (A)
150 | 180 | 250 | 320 | 400 | 600 | 800 | 1000 | 1600 | 2500
-
Operating Voltage (VAC)
520 | 760
Body Features
-
Product Weight (g)
5800 | 6000 | 9000 | 9500 | 10500 | 11000 | 20000 | 21000 | 27000 | 69000
-
Product Weight (oz)
204.58 | 211.64 | 317.46 | 335.1 | 370.37 | 388.01 | 705.47 | 740.75 | 952.39 | 2433.9
Mechanical Attachment
-
Product Mount Type
Chassis Mount
Dimensions
-
Product Width (mm)
210 | 230 | 260 | 280 | 300 | 370
-
Product Width (in)
8.26 | 9.05 | 10.23 | 11.02 | 11.81 | 14.56
-
Product Length (mm)
300 | 350 | 400 | 450
-
Product Length (in)
11.81 | 13.77 | 15.74 | 17.71
-
Product Height (mm)
115 | 120 | 125 | 135 | 160 | 170 | 220
-
Product Height (in)
4.52 | 4.72 | 4.92 | 5.31 | 6.29 | 6.69 | 8.66
Usage Conditions
-
Operating Temperature Range
-25 – 100 °C [ -13 – 212 °F ]
Operation/Application
-
Cooling Method
Natural Convection
Industry Standards
-
UL Flammability Rating
UL 94V-0
-
Pollution Degree
PD2
-
Certified To
CSA 22.2 No. 8 1986 | EN 60721-3 | IEC/EN 60939 | UL 1283
-
IP Rating
IP00
Reference Number
-
TE Internal Number
CAT-P99-F3359
