Please review product documents or contact us for the latest agency approval information.
Product Type Features
-
Filtering Requirements
Unfiltered
-
Input Termination Type
Terminal Block
-
Output Termination Type
Terminal Block
Configuration Features
-
Wiring Configuration
Three Phase
Electrical Characteristics
-
Overvoltage Category
II
-
Leakage Current (Max) (250VAC, 50Hz) (mA)
2.5 | 2.6 | 9.6 | 10.8 | 14.2 | 17.4
-
Current Rating (A)
7 | 16 | 30 | 42 | 55 | 75 | 100 | 130 | 180
-
Operating Voltage (VAC)
520
Body Features
-
Product Weight (g)
500 | 800 | 1200 | 1400 | 2200 | 2900 | 4100 | 4600 | 6000
-
Product Weight (oz)
17.63 | 28.21 | 42.32 | 49.38 | 77.6 | 102.29 | 144.62 | 162.26 | 211.64
Mechanical Attachment
-
Product Mount Type
Chassis Mount
Dimensions
-
Product Width (mm)
40 | 45 | 50 | 80 | 85 | 90 | 120
-
Product Width (in)
1.57 | 1.77 | 1.96 | 3.14 | 3.34 | 3.54 | 4.72
-
Product Length (mm)
160 | 220 | 240 | 264 | 280 | 350
-
Product Length (in)
6.29 | 8.66 | 9.44 | 10.39 | 11.02 | 13.77
-
Product Height (mm)
70 | 85 | 90 | 135 | 150 | 170
-
Product Height (in)
2.75 | 3.34 | 3.54 | 5.31 | 5.9 | 6.69
Usage Conditions
-
Operating Temperature Range
-25 – 100 °C [ -13 – 212 °F ]
Operation/Application
-
Cooling Method
Natural Convection
Industry Standards
-
UL Flammability Rating
UL 94V-0
-
Pollution Degree
PD2
-
Certified To
CSA 22.2 No. 8 1986 | IEC/EN 60939 | UL 1283
-
IP Rating
IP20
Reference Number
-
TE Internal Number
CAT-P99-F3268
