Please review product documents or contact us for the latest agency approval information.
Product Type Features
-
Filtering Requirements
Unfiltered
-
Input Termination Type
Busbar | Ring Terminal | Terminal Block
-
Output Termination Type
Busbar | Ring Terminal | Terminal Block
Configuration Features
-
Wiring Configuration
Three Phase
Electrical Characteristics
-
Overvoltage Category
II
-
Leakage Current (Max) (250VAC, 50Hz) (mA)
6.8 | 9.3 | 10
-
Current Rating (A)
35 | 50 | 80 | 110 | 150 | 200 | 230 | 300
-
Operating Voltage (VAC)
520
Body Features
-
Product Weight (g)
2300 | 3400 | 4250 | 5000 | 5200 | 5400 | 8500 | 9100 | 9200 | 11800
-
Product Weight (oz)
81.13 | 119.93 | 149.91 | 176.36 | 183.42 | 190.47 | 299.82 | 320.99 | 324.52 | 416.23
Mechanical Attachment
-
Product Mount Type
Chassis Mount
Dimensions
-
Product Width (mm)
60 | 80 | 90 | 110 | 200
-
Product Width (in)
2.36 | 3.14 | 3.54 | 4.33 | 7.87
-
Product Length (mm)
330 | 339 | 395 | 451 | 505
-
Product Length (in)
12.99 | 13.34 | 15.55 | 17.75 | 19.88
-
Product Height (mm)
150 | 185 | 200 | 220 | 240
-
Product Height (in)
5.9 | 7.28 | 7.87 | 8.66 | 9.44
Usage Conditions
-
Operating Temperature Range
-25 – 100 °C [ -13 – 212 °F ]
Operation/Application
-
Cooling Method
Natural Convection
Industry Standards
-
UL Flammability Rating
UL 94V-0
-
Pollution Degree
PD2
-
Certified To
CSA 22.2 No. 8 1986 | IEC/EN 60939 | UL 1283
-
IP Rating
IP20
Reference Number
-
TE Internal Number
CAT-P99-F3100
