Please review product documents or contact us for the latest agency approval information.
Product Type Features
-
Filtering Requirements
Unfiltered
-
Input Termination Type
FASTON | Litz Wire | Ring Terminal | Threaded Stud
-
Output Termination Type
FASTON | Litz Wire | Ring Terminal | Threaded Stud
Electrical Characteristics
-
Inductance L1 (µH)
1.23 | 2 | 2.8 | 3.25 | 4.5 | 7.8 | 9.8 | 22
-
Overvoltage Category
II
-
Capacitance Cx1
.33 | .47 | 1 | 2.2
-
Capacitance Cy1
.47 | 4.7 | 33 | 47
-
Current Rating (A)
1 | 3 | 6 | 10 | 12 | 16 | 25 | 36
-
Leakage Current (Max) (120VAC, 60Hz) (mA)
0 | .04 | .38 | 2.13
-
Leakage Current (Max) (250VAC, 50Hz) (mA)
0 | .07 | .66 | 2.59 | 3.69
-
Operating Voltage (VAC)
250
Body Features
-
Product Weight (g)
130 | 154 | 160 | 170 | 190 | 200 | 220 | 230 | 250 | 370 | 450 | 500 | 583 | 598 | 600 | 613 | 636 | 670 | 700 | 701 | 710 | 730 | 750 | 790 | 795 | 810 | 1000
-
Product Weight (oz)
4.58 | 5.43 | 5.64 | 5.99 | 6.7 | 7.05 | 7.76 | 8.11 | 8.81 | 13.05 | 15.87 | 17.63 | 20.56 | 21.09 | 21.16 | 21.62 | 22.43 | 23.63 | 24.69 | 24.72 | 25.04 | 25.74 | 26.45 | 27.86 | 28.04 | 28.57 | 35.27
Mechanical Attachment
-
Product Mount Type
Chassis Mount
Dimensions
-
Product Width (mm)
49.8 | 56 | 57.5 | 84.5 | 85.5
-
Product Width (in)
1.96 | 2.2 | 2.26 | 3.32 | 3.36
-
Product Length (mm)
64.8 | 94 | 98.5 | 119 | 130 | 130.5 | 156
-
Product Length (in)
2.55 | 3.7 | 3.87 | 4.68 | 5.11 | 5.13 | 6.14
-
Product Height (mm)
30.3 | 40.3 | 45.4 | 45.5 | 54.4 | 57.6
-
Product Height (in)
1.19 | 1.58 | 1.78 | 1.79 | 2.14 | 2.26
Usage Conditions
-
Operating Temperature Range
-25 – 100 °C [ -13 – 212 °F ]
Operation/Application
-
Cooling Method
Natural Convection
-
Operating Altitude (Max) (m)
2000
Industry Standards
-
UL Flammability Rating
UL 94V-0
-
Pollution Degree
PD2
-
Certified To
CSA 22.2 No. 8 1986 | IEC/EN 60939 | UL 1283
-
IP Rating
IP00
Reference Number
-
TE Internal Number
CAT-P97-F2070
