P8 Pin Insertion Machines

P8 Pin Insertion Machines-CAT-P8
TE’s next-generation P8 pin insertion machine offers best-in-class speed and sustainability by allowing less power consumption, increased tool lifetime and quality management providing foolproof changeover and traceability within automotive, energy, industrial, consumer electronics and appliances industries.
More Less

Available from

LADD Inc

Build and price the product now

Overview
  1. P8 Pin Insertion Machine 3D Animation

Explore the precision engineering of our P8 Pin Insertion Machine through this 3D visualization, showcasing its innovative structure and efficient operation process.

p8 3d video
Brochure
P8 Pin Insertion Machines Brochure (English)
Catalog (English)
NEXT-GEN Pin Insertion Machines

3

Maximum Insertion Rate Per Second

4

Up to 4 Insertion Heads

<10

Changeover with Conversion Kit in Less Than 10 Minutes

Features and Benefits

  • Board capacity up to 420 x 360mm [16.5" x 14.2”]
  • Up to 4 insertion heads
  • Optional programmable insertion angle (rotation of up to +/- 90-degress doesn’t influence insertion rate)
  • Insertion rate up to 3 cycles/second
  • Single, double and triple pin insertion
  • Anvil Drive: Servo Spindle
  • Optional trouble shooting support
  • Real-time force monitoring for 100% quality assurance (maximum force and force vs. distance monitoring)
  • Maximum Insertion Force 1000N
  • Vision system for PCB alignment accuracy
  • Touch screen provides simple programming and an intuitive operator interface
  • Board error correction vision system
  • Optional traceability capabilities
  • Industry 4.0 ready with modularization options

Applications

  • PCBs
  • ​Connectors
  • ​Plastic Housings​
  • Power Modules e.g. IGBTs
  • Mold Inlays

Contacts

  • Press fit / Non-Press fit (Solder)
  • Pins, Tabs & Sockets
  • Fuse holders
  • Fork contacts
  • F-Posts 90° ·
  • Board to Board contacts
  • Continuous Wire
  • Special contacts
  • Holetite (on mylar tape)
  • Screw sockets (bulk)
  • Contacts that need bending
  1. Pin Insertion Machines Overview (English)

Learn more about our Pin Insertion Machines, which are engineered to apply products from TE and other manufacturers to meet your diverse production requirements.

Pin Insertion Machines Overview (English)
Pin Insertion Machine

Product Group

Pin Insertion Machines

TE provides a wide range of Pin Insertion Machines, from stand-alone to semi and fully automatic, with flexibility to meet a range of needs.

Product Group

P8 Pin Insertion Machine

TE’s next-generation P8 pin insertion machine offers best-in-class speed and sustainability by allowing less power consumption, increased tool lifetime and quality management providing foolproof changeover and traceability within automotive, energy, industrial, consumer electronics and appliances industries.

Pin Insertion Contact US

Pin Insertion Contact US

TE Connectivity's (TE) industry-leading performance, engineered for speed and precision pin insertion machine portfolio, maximizes throughput while minimizing downtime, allowing you to achieve your production goals with uncompromised quality.
