DT-XT 18-way Plug Connectors

DT-XT 18-way Plug Connectors-CAT-J4A-DPC18
More Less

Product Features

  • Number of Positions : 18

  • Connector & Housing Type : Plug

  • Mating Pin Diameter : 1.55 mm [ .061 in ]

  • Connector System : Wire-to-Wire

  • Centerline (Pitch) : 4.66 mm [ .183 in ]

Available from

LADD Inc
Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

  • Mixed & Hybrid Connector  No

  • Connector Shape  Rectangular

  • Connector & Housing Type  Plug

  • Connector System  Wire-to-Wire

  • Sealable  Yes

  • Primary Locking Feature  Integrated in Housing

  • Connector & Contact Terminates To  Wire & Cable

Configuration Features

  • Number of Positions  18

  • Number of Rows  3

Body Features

  • Primary Product Color  Black

  • Connector & Keying Code  A, B, C, D, E

Contact Features

  • Contact Size  Size 16

  • Mating Pin Diameter  1.55 mm [ .061 in ]

Mechanical Attachment

  • Mating Alignment  With

  • Mating Alignment Type  Keyed

  • Connector Mounting Type  Cable Mount (Free-Hanging)

Housing Features

  • Centerline (Pitch)  4.66 mm [ .183 in ]

Usage Conditions

  • Operating Temperature (Max)  125 °C [ 257 °F ]

  • Operating Temperature Range  -55 – 125 °C [ -67 – 257 °F ]

Operation/Application

  • Circuit Application  Power

Packaging Features

  • Packaging Quantity  400

Other

  • Connector Position Assurance Capable  No

Reference Number

  • TE Internal Number CAT-J4A-DPC18
