MT FEP Heat Shrink Tube: Single Wall
FEP is a fluorinated ethylene propylene (FEP) heat shrink tubing used as processing aid for reflowing catheter shafts and joint bonding, offering excellent consistency, high dielectric strength and is chemically inert.
Product Features
-
Primary Product Color : Clear
-
Wall Type : Single Wall
-
Expanded Inside Diameter (Min) (mm): .79 | 1.19 | 1.59 | 2.38 | 3.18 | 4.76 | 6.35 | 9.53
-
Expanded Inside Diameter (Min) (in): .031 | .047 | .063 | .094 | .125 | .188 | .25 | .375
-
Recovered Inside Diameter (Max) (mm): .5 | .76 | .99 | 1.42 | 1.91 | 2.92 | 3.81 | 5.72
-
Recovered Inside Diameter (Max) (in): .02 | .03 | .039 | .056 | .075 | .115 | .15 | .225
-
Tubing Product Type : Heat Shrink Tubing
Overview
Profile
- Shrink ratio ≤ 1.6:1
- Full recovery at 210°C (410°F) minimum
- Tight longitudinal change control as low as ± 2%
- Custom sizing, finishing options available
- Translucent for high optical clarity
About
- FEP is lubricious and semi-rigid with shrink ratios up to 2:1*.
- FEP is the industry gold standard for reflowing catheter shafts and bonding joints.
- For our FEP, we can control longitudinal growth ± 2% ensuring consistency on lot-to-lot, reducing waste and cost
Features
Please review product documents or contact us for the latest agency approval information.
Product Type Features
-
Wall Type Single Wall
-
Tubing Product Type Heat Shrink Tubing
Body Features
-
Primary Product Color Clear
-
Shrink Ratio 1.61:1
-
Primary Product Material Fluoropolymer
-
Flexibility Semi-Rigid
Dimensions
-
Recovered Wall Thickness (Nominal) (mm) .2 | .25 | .3 | .38
-
Recovered Wall Thickness (Nominal) (in) .008 | .01 | .012 | .015
-
Product Length 1219 mm [ 48 in ]
-
Expanded Inside Diameter (Min) (mm) .79 | 1.19 | 1.59 | 2.38 | 3.18 | 4.76 | 6.35 | 9.53
-
Expanded Inside Diameter (Min) (in) .031 | .047 | .063 | .094 | .125 | .188 | .25 | .375
-
Recovered Inside Diameter (Max) (mm) .5 | .76 | .99 | 1.42 | 1.91 | 2.92 | 3.81 | 5.72
-
Recovered Inside Diameter (Max) (in) .02 | .03 | .039 | .056 | .075 | .115 | .15 | .225
Usage Conditions
-
Shrink Temperature (Min) (°C) 210
-
Tubing Flammability Type Non-Flame-Retardant
-
Operating Temperature Range -70 – 190 °C [ -94 – 374 °F ]
-
Recovery Temperature (°C) 210
Operation/Application
-
Mechanical Resistance Fluids
Product Availability
-
Applicable Region Americas | Asia | EMEA
Packaging Features
-
Packaging Method Stick
Other
-
Product Source US
Reference Number
-
TE Internal Number CAT-G62-MFHSTSW0
