DC Contactor: Small SPST 200A

DC Contactor: Small SPST 200A-CAT-DC-K200
TE's HARTMAN K200 Series contactors are the lightweight and highly efficient 200 A power switching solution for harsh 28 VDC aerospace and defense applications.
More Less
Connect with Us

Product Features

  • Relay & Contactor Type : General Purpose Contactor

  • Contact Current Rating (A): 200

  • Contact Arrangement : SPST NO DB

  • Current Type : DC

  • Coil Voltage Rating (VDC): 28 | 32

Available from

LADD Inc
Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

  • Relay & Contactor Type  General Purpose Contactor

Configuration Features

  • Auxiliary Switch Contact Arrangement  2PDT | None

  • Contact Arrangement  SPST NO DB

  • Contact Number of Poles  1

Electrical Characteristics

  • Contact Switching Voltage (Max) (VDC) 28

  • Contact Current Rating (A) 200

  • Coil Voltage Rating (VDC) 28 | 32

  • Coil Resistance (Ω) 120

Body Features

  • Enclosure Type  Environmentally Sealed

Termination Features

  • Auxiliary Termination & Connection Type  D-Sub

  • Main Termination & Connection Type  Bus Bar

  • Coil Termination & Connection Type  D-Sub | Flying Leads

Mechanical Attachment

  • Product Mounting Feature Type  Mounting Plate

  • Product Mount Type  Bus Bar Mount | Chassis Mount

Operation/Application

  • Current Type  DC

Other

  • Contact Current Class (A) >50 – ≤200
