ERNI MicroBridge Flexfoil Female

ERNI MicroBridge Flexfoil Female-CAT-0B5-MCBFF
Designed to satisfy the rigorous requirements of both industrial and automotive environments, the MicroBridge connector stands out for its versatility and robust performance. The Flexfoil female variant, in particular, provides an effective foil-to-board connection solution, expanding the range of design possibilities. This product is available in configurations of up to 20 pins. Moreover, every version of the Flexfoil female connector is fully compatible with ERNI MicroBridge male connectors of corresponding positions, ensuring seamless integration across different setups.
More Less
Connect with Us

Product Features

  • Connector Product Type : Connector Assembly

  • Connector & Housing Type : Receptacle

  • Mating Retention Type : Latching Feature

  • Connector System : Wire-to-Board

  • UL Flammability Rating : UL 94V-0

Available from

LADD Inc
Features

Please review product documents or contact us for the latest agency approval information.

Product Type Features

  • Connector Product Type  Connector Assembly

  • Connector & Housing Type  Receptacle

  • Connector System  Wire-to-Board

  • Sealable  No

  • Connector & Contact Terminates To  Wire & Cable

Configuration Features

  • Number of Positions  8 | 14 | 20

  • Number of Rows  1

Electrical Characteristics

  • Operating Voltage (VDC) 63

Body Features

  • Primary Product Color  Black

Contact Features

  • Contact Layout  Inline

  • Contact Base Material  Copper Alloy

  • Contact Current Rating (Max) (A) 9

  • Contact Type  Receptacle

Termination Features

  • Termination Method to Wire & Cable  Insulation Displacement (IDC)

Mechanical Attachment

  • Mating Retention Type  Latching Feature

  • Mating Retention  With

  • Connector Mounting Type  Free-Hanging (In-Line)

Housing Features

  • Centerline (Pitch)  1.27 mm [ .05 in ]

  • Housing Material  Polyphthalamide (PPA) GF30

Usage Conditions

  • Operating Temperature Range  -40 – 150 °C [ -40 – 302 °F ]

Operation/Application

  • Circuit Application  Power & Signal

Industry Standards

  • UL Flammability Rating  UL 94V-0

Packaging Features

  • Packaging Method  Tray
