Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector & Housing Type : Plug

• Connector System : Wire-to-Wire

• Insertion Force Type : Normal

• Sealable : Yes

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 5

• Number of Rows : 2

• Contact Type : Socket

• Contact Size : Size 20

• Contact Retention Within Housing : With

• Contact Current Rating (Max) (A): 7.5

• Contact Retention Type Within Housing : Crimp Snap-In

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Mating Retention Type : Latch

• Connector Mounting Type : Panel Mount

• Housing Material : Composite

• Wire Size (AWG): 24 – 20

• Operating Temperature Range : -65 – 175 °C [ -85 – 347 °F ]
