• Connector Shape : Rectangular

• Mixed & Hybrid Connector : Yes

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Board

• Sealable : Yes

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 46

• Number of Rows : 3

• Cable Exit Angle : 180°

• Primary Product Color : Black

• Connector & Keying Code : A

• Contact Type : Receptacle

• Contact Size : .64mm, 2.8mm, 6.3mm

• Mating Tab Width (mm): .64, 2.8, 6.3

• Mating Tab Width (in): .025, .11, .25

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : Yes

• Strain Relief : With

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Housing Material : PBT GF20

• Centerline (Pitch) (mm): 3.8, 6

• Centerline (Pitch) (in): .149, .236

• Connector Height : 43.5 mm [ 1.71 in ]

• Product Length : 92 mm [ 3.62 in ]

• Product Width : 36.6 mm [ 1.44 in ]

• Row-to-Row Spacing (mm): 4.5, 8.5

• Row-to-Row Spacing (in): .18, .34

• Packaging Method : Package

• Packaging Quantity : 90
