• Antenna Product Type : Antenna

• Antenna Style : Stamped

• Antenna Type : Stamped Metal

• Band Type : Multi Band

• Mounting Location : Internal/Embedded

• Port Configuration : Single Port

• VSWR (Max) : <2.5:1

• Antenna Operation : Passive

• Impedance (Ω): 50

• Gain (Max) (dB): 3.2

• Frequency Band (MHz): 617 – 960, 1710 – 2690, 5925 – 7125, 1427 – 1608, 3300 – 3800, 5150 – 5875, 4300 – 4700

• Frequency Category : 617 – 7125

• Peak Gain (dBi): 3 < 6

• Product Weight : 6.5 g [ .229 oz ]

• Polarization : Linear

• Mounting Type : Surface Mount

• Product Height : 15.01 mm [ .591 in ]

• Product Length : 52 mm [ 2.04 in ]

• Product Width : 21.4 mm [ .842 in ]

• Wireless Standard : 802.11 a/b/g/n, Bluetooth & ZigBee, 802.11 a/b/g/n/ac/ad, Bluetooth, ZigBee & Wi-Fi, 802.11 a/b/g/n/ac/ad/ax, Bluetooth, ZigBee & Wi-Fi, 802.11 a/g/n/ac & Wi-Fi, 802.11 b/g, Bluetooth & ZigBee, 915 ISM & ZigBee US, EU Cellular, Global Cellular 2G/3G, GPS, LTE, UMTS, GSM, US Cellular & ZigBee EU

• Directionality : Omnidirectional

• Primary Application : 5G, Cat-M/NB-IoT, Cellular

• Wireless Application : 5G, Bluetooth, Cat-M/NB-IoT, CBRS, Cellular, GNSS, GPS, ISM, LoRaWAN, Wi-Fi

• Applicable Region : Global

• Packaging Method : Tray
