KLN700A1/4
Aluminum, Straight Knurl Knob Design, 6.35 mm [.25 in] Shaft, 18.8 mm [.74 in] Diameter, Natural, Line Indicator, Alcoswitch KLN, Switch Knobs
KLN700A1/4
Aluminum, Straight Knurl Knob Design, 6.35 mm [.25 in] Shaft, 18.8 mm [.74 in] Diameter, Natural, Line Indicator, Alcoswitch KLN, Switch Knobs
-
- Alcoswitch
- Alcoswitch KLN
- TE Internal #: 1437622-2
- TE Internal Description: KLN700A1/4=KNOB KNURL W/IND LI
-
Primary Product Material : Aluminum
-
Knob Design : Straight Knurl
-
Shaft Size : 6.35 mm [ .25 in ]
-
Product Diameter : 18.8 mm [ .74 in ]
-
Primary Product Color : Natural
Documents
Product Drawings
- OUTLINE DWG. KNOB (KLN SERIES) ENG_CD_1437622-1_B_1437622-1-c.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_1437622-2_99.pdf 3D
- Customer View Model ENG_CVM_CVM_1437622-2_99.2d_dxf.zip English
- ENG_CVM_CVM_1437622-2_99.3d_igs.zip English
- ENG_CVM_CVM_1437622-2_99.3d_stp.zip English
Datasheets & Catalog Pages
- Alcoswitch Products ENG_DS_1308390_Alcoswitch_1004.pdf English
