Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector Shape : Rectangular

• Mixed & Hybrid Connector : No

• Connector & Housing Type : Housing for Female Terminals

• Connector System : Wire-to-Wire

• Sealable : No

• Primary Locking Feature : Integrated in Housing

• Connector & Contact Terminates To : Wire & Cable

• Number of Positions : 4

• Number of Rows : 1

• Nominal Voltage Architecture (V): 16

• Primary Product Color : Black

• Connector & Keying Code : A1

• Contact Type : Receptacle

• Contact Size : 2.8mm

• Mating Tab Width : 2.8 mm [ .11 in ]

• Contact Current Rating (Max) (A): 10

• Mating Alignment : With

• Mating Alignment Type : Keyed

• Terminal Position Assurance : No

• Strain Relief : Without

• Connector Mounting Type : Cable Mount (Free-Hanging)

• Housing Material : PBT GF

• Centerline (Pitch) : 5 mm [ .197 in ]

• Connector Height : 21 mm [ .826 in ]

• Product Length : 46.3 mm [ 1.82 in ]

• Product Width : 37.75 mm [ 1.48 in ]

• Operating Temperature (Max) : 100 °C [ 212 °F ]

• Operating Temperature Range : -40 – 100 °C [ -40 – 212 °F ]

• Circuit Application : Signal

• Packaging Method : Box
