Please review product documents or contact us for the latest agency approval information.

• Connector Product Type : Connector Assembly

• Prewired : No

• Connector System : Wire-to-Panel

• Sealable : Yes

• Connector & Contact Terminates To : Wire & Cable

• Circular Connector Type : Receptacle

• Shell Type : Square Flange

• Number of Positions : 3

• Number of Power Positions : 0

• Number of Signal Positions : 3

• Contacts Preloaded : No

• Operating Voltage (VDC): 115

• Operating Voltage (VAC): 115

• Primary Product Color : Natural

• Environmental Protection Type : Elastomer Sealed

• Shell Plating Material : Cadmium

• Shell Base Material : Aluminum

• Circular Connector Insulation Material Type : Thermoset

• Hermetically Sealed : No

• Contact Current Rating (Max) (A): 7.5

• Reverse Gender : No

• Contact Layout Arrangement : 8 – 3

• Circular Connector Contact Type : Less Socket

• Termination Method to Wire & Cable : Crimp

• Panel Mount Feature Type : Square Flange

• Connector Mounting Type : Panel Mount

• Circular Connector Shell Size : 08

• Wire Size (AWG): 20 – 24

• Wire Size (mm²): .2 – .52

• Operating Temperature Range : -65 – 175 °C [ -85 – 347 °F ]
