H56C422NN00003200000
7 Position Circular Connector, Cable-to-Cable, Power & Signal, Panel Mount, Electrodeposited Zinc, Zinc Die Cast, PA66, 5 Power Positions
H56C422NN00003200000
7 Position Circular Connector, Cable-to-Cable, Power & Signal, Panel Mount, Electrodeposited Zinc, Zinc Die Cast, PA66, 5 Power Positions
- TE Internal #: HGC422N00003200000
- TE Internal Description: 723 htec receptacle, angled, speedtec
-
Number of Positions : 7
-
Connector System : Cable-to-Cable
-
Sealable : No
-
Circuit Application : Power & Signal
-
Connector Mounting Type : Panel Mount
Documents
Product Drawings
- 723 HTEC RECEPTACLE, ANGLED, ROTATABLE SPEEDTEC, FLANGE 25X25, 5+2PIN ENG_CD_HGC422N00003200000_A.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_HGC422N00003200000_A.pdf 3D
- Customer View Model ENG_CVM_CVM_HGC422N00003200000_A.2d_dxf.zip English
- ENG_CVM_CVM_HGC422N00003200000_A.3d_igs.zip English
- ENG_CVM_CVM_HGC422N00003200000_A.3d_stp.zip English
Datasheets & Catalog Pages
- fuer Datenblaetter, die online konfigurierbar sind GER_DS_Konfigurator_1.pdf German
