MTA 156 connector

Lower Your Applied Cost

Reduce labor, lower costs, and simplify assembly processes. Mass terminate wires with our MTA connector system. Mass termination of wires provides a lower applied cost because it drastically reduces the labor content of virtually any cable or harness assembly required. The wire-to-board and wire-to-wire system is based on insulation displacement contact (IDC) technology. Insulation displacement contacts (IDC) are used to terminate a wide range of conductor sizes. Our design features wire feed-through capability for daisy-chain applications and ribbon cable can also be terminated when the appropriate receptacle assembly and strain relief cover are used. Header assemblies for board mount applications include right-angle and vertical mount products available in through-hole and surface mount configurations.

Reduce your labor through mass termination of wires

Lower Your Applied Cost

Simplify your assembly process with IDC technology

Product Features

MTA Connector System

MTA 100 connectors

  • Single row on a .100 [2.54] centerline
  • 2-28 positions, shrouded headers 2-14
  • Terminates 28-22 AWG discrete wire or notched ribbon cable
  • 250V, 5A rating



MTA 156 connectors

  • Single row on a .156 [3.96] centerline
  • 2-24 positions
  • Terminates 18-26 AWG
  • 600V, up to 7A rating



Both Types

  • Color coded housing for wire gage
  • Tin, 15 and 30 gold plating options
  • Audible latch for wire-to-wire (posted) housings
