ANT-DB1-RAF-RPS
Terminal/Duck Antenna, Triple Band, Wi-Fi, External Mount, Stud/Screw/Lug Mount, N-type, Omnidirectional, Single Port, 3 < 6 dBi Peak Gain
ANT-DB1-RAF-RPS
Terminal/Duck Antenna, Triple Band, Wi-Fi, External Mount, Stud/Screw/Lug Mount, N-type, Omnidirectional, Single Port, 3 < 6 dBi Peak Gain
- TE Internal #: ANT-DB1-RAF-RPS
- TE Internal Description: Antenna WiFi6/6E Swivel RPS
-
Antenna Type : Terminal/Duck
-
Band Type : Triple Band
-
Primary Application : Wi-Fi
-
Wireless Application : Wi-Fi
-
Mounting Location : External
Documents
Product Drawings
- ANTENNA DUAL BAND 45 DEGREE/ 90 DEGREE POSITIONABLE ENG_CD_C-ANT-FFF-RAF-CCC_A.pdf English
CAD Files
-
Download ECAD Model File
Download the free Library Loader to convert this file to your ECAD Tool. Learn more about the ECAD Model.
- 3D PDF 3D_CVM_CVM_ANT-DB1-RAF-RPS_A1.pdf 3D
- Customer View Model ENG_CVM_CVM_ANT-DB1-RAF-RPS_A1.2d_dxf.zip English
- ENG_CVM_CVM_ANT-DB1-RAF-RPS_A1.3d_igs.zip English
- ENG_CVM_CVM_ANT-DB1-RAF-RPS_A1.3d_stp.zip English
Datasheets & Catalog Pages
- Hinged Blade WiFi 6/5/4 Antenna ENG_DS_ANT-DB1-RAF_A.pdf English
