Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Input Termination Type : Busbar

• Output Termination Type : Busbar

• Short Circuit Current Rating (kA): 100

• Overvoltage Category : III

• Operating Voltage (Max) (VAC): 500

• Motor Drive Input Current (A): 656

• Rated Load Power (kW): 370

• Product Weight (g): 295000

• Product Mount Type : Floor Mount

• Product Height : 1120 mm [ 44.09 in ]

• Product Length : 650 mm [ 25.59 in ]

• Product Width : 505 mm [ 19.88 in ]

• Required DC Line Inductance (Min) : .07

• Compatible with Motor Drive Type : 6 Pulse Diode Rectifier & SCR

• Rated Voltage & Power Efficiency : >98%

• Operating Altitude (Max) (m): 2000

• Target THDi @ Rated Power (%): <8

• Cooling Method : Active Air Cooling

• Certified To : EN 60076-6, UL/IEC/EN 61800-5-1

• Pollution Degree : PD3

• UL Flammability Rating : UL 94V-0

• IP Rating : IP00
