Dynamic Ultra Series Receptacle Assembly
The dynamic ultra connector series from TE Connectivity (TE) is engineered as a miniature wire-to-board interconnection system. Its multiple contact points provides for reliable performance even in demanding environments, such as electric vehicle (EV) powertrains, battery packs, and automotive lighting applications
Product Features
-
Connector Product Type : Housing Assembly
-
Connector & Housing Type : Plug
-
Mating Retention : With
-
Termination Method to Wire & Cable : Crimp
-
Connector System : Wire-to-Board
Overview
The Dynamic Ultra connector series from TE Connectivity (TE) is engineered as a miniature wire-to-board interconnection system. Its multiple contact points provide for reliable performance even in demanding environments, such as electric vehicle (EV) powertrains, battery packs, and automotive lighting applications. Featuring a secondary locking mechanism, the Dynamic Ultra connector Series complies with the LV 214 standard, making it suitable for specialized automotive applications.
Features
Please review product documents or contact us for the latest agency approval information.
Product Type Features
-
Connector Product Type Housing Assembly
-
Connector & Housing Type Plug
-
Connector System Wire-to-Board
-
Sealable No
Configuration Features
-
Number of Positions 2, 6, 10
-
Number of Rows 1
Body Features
-
Primary Product Color Black, Natural
Contact Features
-
Contact Current Rating (Max) (A) 3
Termination Features
-
Termination Method to Wire & Cable Crimp
Mechanical Attachment
-
Mating Retention With
Housing Features
-
Centerline (Pitch) 1.8 mm [ .072 in ]
Usage Conditions
-
Operating Temperature Range -40 – 125 °C [ -40 – 257 °F ]
Operation/Application
-
Circuit Application Power & Signal
Reference Number
-
TE Internal Number CAT-432-DURA
