1703104-1 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 5
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
927157-1 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 4
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material Nylon
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -25 – 105
  • Circuit Application Power
928017-1 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 9
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material Polyamide 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -25 – 105
  • Circuit Application Power
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 750
964450-3 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Printed Circuit Board
  • Keying Code A
  • Number of Positions 14
  • Number of Rows 1
  • Contact Type Socket
  • Contact Retention Within Housing Without
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material PA66 GF35
  • Centerline (Pitch) 6.5
  • Housing Color Red
  • Circuit Application Power & Signal
  • Packaging Method Box
  • Packaging Quantity 148
1703129-1 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 8
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 600
927155-1 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 2
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material Nylon
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Circuit Application Power & Signal
927156-1 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 3
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material Nylon
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -25 – 105
  • Circuit Application Power
1703081-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 3
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 2000
964768-3 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 2
  • Number of Rows 1
  • Termination Method to Wire & Cable Crimp
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material PA 6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
1703128-1 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 8
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
2-928344-6 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 6
  • Number of Rows 1
  • Termination Method to Wire & Cable Crimp
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Cable Mount (Free-Hanging)
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power
1-1241967-5 Wire-to-Board Connector Housings  1
RAST
  • Connector System Wire-to-Wire
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 10
  • Number of Rows 1
  • Termination Method to Wire & Cable Crimp
  • Mating Retention Type Lock
  • Mating Retention With
  • Connector Mounting Type Panel
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -25 – 105
  • Circuit Application Power
1-1703072-5 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 2
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Without
  • Connector Mounting Type Board Mount
  • Housing Material PA 6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 750
1-1703077-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 2
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention With
  • Connector Mounting Type Board Mount
  • Housing Material PA 6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 250
1-1703079-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 3
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Without
  • Connector Mounting Type Board Mount
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 1000
1-1703080-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 3
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Without
  • Connector Mounting Type Board Mount
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 2000
1-1703082-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 3
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Without
  • Connector Mounting Type Board Mount
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 2000
1-1703083-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 3
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Without
  • Connector Mounting Type Board Mount
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 2000
1-1703095-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 4
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Type Locking Latch
  • Mating Retention With
  • Connector Mounting Type Board Mount
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 2000
1-1703097-1 Wire-to-Board Connector Housings
RAST
  • Connector System Wire-to-Board
  • Sealable No
  • Connector & Contact Terminates To Wire & Cable
  • Number of Positions 4
  • Number of Rows 1
  • Termination Method to Wire & Cable Insulation Displacement Crimp (IDC)
  • Mating Retention Without
  • Connector Mounting Type Board Mount
  • Housing Material PA 6.6
  • Centerline (Pitch) 5
  • Housing Color Natural
  • Operating Temperature Range -40 – 105
  • Circuit Application Power & Signal
  • UL Flammability Rating UL 94V-2
  • Packaging Method Bag/Box
  • Packaging Quantity 2000
