Application
Automotive Infotainment
TE's technologies are focused on consumer port applications, board-to-board connections, vehicle-to-vehicle communication, and next-generation harness architecture. Our infotainment products provide the next generation of connected vehicles with fast, reliable, and responsive connectivity solutions.
Infotainment links have high-performance requirements for high data rates and time-synchronous data streams on multiple devices. Consequently, appropriate links must be designed for optimal signal integrity properties at high frequencies. Typically, infotainment links are used as point-to-point connections (e.g. display links for high resolution dashboards, control panels or HUDs, and in a ring bus configuration). In the future, open protocols, such as audio-video bridging (AVB), might also enable the implementation of automotive network topologies. They would ensure that multiple data streams are made available in a timely basis across different devices. TE offers connector solutions to support automotive infotainment applications; typical applications and featured TE products include:
Interior Lighting
Interior lighting systems to support human machine interfaces (HMI) in automotive infotainment systems.
Interior Lighting
MATEnet Modular and Scalable Connectors
TE plays a major role in connecting critical electronic vehicle networks that enable transmission of data from sensors and systems. TE’s MATEnet modular and scalable connectors have been able to show a data transmission rate of 100 Mbit/s and 1 Gbit/s according to IEEE 100BASE-T1/1000BASE-T1. This can be achieved with standard automotive connectors based on TE’s miniaturized NanoMQS termination system in combination with unshielded twisted-pair (UTP) cable or shielded twisted-pair (STP) cable.

Interior Lighting
Through-Hole Resistors
A through-hole resistor is a fixed resistor that has long, pliable leads that can be stuck into a breadboard or hand- or wave-soldered into a printed circuit board. A through-hole resistor is used to reduce the flow of electrical current within a circuit. It’s commonly composed of carbon film, metal film, metal oxide film, thick film, or wirewound.

Interior Lighting
Surface Mount Resistors
A surface mount resistor is a tiny rectangular ceramic body with silver conductive edges on either end. They provide the same functionality as the more traditional axially leaded resistors but has a lower power dissipation capacity and oftentimes a lower stray inductance and capacity.

Interior Lighting
DIP & SIP Switches
A DIP switch is a manual electronic package that is composed of a series of tiny switches. It has a rectangular casing and two parallel rows of connecting terminals. A SIP switch is a computer chip package that has a single row of connection pins.

Interior Lighting
Tactile Switches
Tactile switches provide tactile feedback to the user when the switch or button makes contact with the control panel underneath, which is usually a printed circuit board.

Infotainment Cluster
Infotainment clusters provide a centralized instrumentation dashboard for the vehicle's infotainment functions such as in-car entertainment (ICE) and in-vehicle infotainment (IVI).
Infotainment Cluster
MATE-AX Miniaturized Coax Connector System
TE's MATE-AX automotive coax connector system provides an EMI resistant and miniaturized interconnection solution for coax lines. A highly robust coax connector system for analog signal and digital data transport applications, it delivers superior data rate performance up to 9GHz and up to 20GHz with optimized designs. TE’s MATE-AX connector system provides advanced automotive coaxial technology for data transmission performance. By offering a higher packaging density, MATE-AX terminals support size and weight reduction which contributes to higher fuel efficiency.

Infotainment Cluster
Trimmer Resistors
A trimmer resistor is a type of variable resistor or adjustable potentiometer that can adjust, tune, and calibrate circuits. It is meant to never be seen or adjusted by the device’s user.

Infotainment Cluster
MATEnet Modular and Scalable Connectors
TE plays a major role in connecting critical electronic vehicle networks that enable transmission of data from sensors and systems. TE’s MATEnet modular and scalable connectors have been able to show a data transmission rate of 100 Mbit/s and 1 Gbit/s according to IEEE 100BASE-T1/1000BASE-T1. This can be achieved with standard automotive connectors based on TE’s miniaturized NanoMQS termination system in combination with unshielded twisted-pair (UTP) cable or shielded twisted-pair (STP) cable.

Infotainment Cluster
Probe Pads
Probe pads are incorporated in circuitry to avoid damage to sensitive tiny electronic circuits in surface mount devices. Probe pads enable safe probing of circuitry when adjusting, setting up, measuring, or repairing tiny electronic circuitry.

Infotainment Cluster
Snap Action Switches
A snap action switch is a mechanical switch that sends a rapid transfer of contacts from one position to another. Also known as micro switches, snap action switches can be momentary or maintained contact and come in subminiature, miniature, and standard styles.

Infotainment Cluster
Fiber Optic Connections for MOST Networks
We offer a broad product range of physical layer components for devices communicating on Media Oriented System Transport (MOST) network. TE Connectivity’s (TE) fiber optics provide a complete range of components for MOST 25 and MOST 150 connectors including PCB and harness connectors, cable assemblies and processing equipment. The development of these components is backed by TE’s knowledge of optics and collaboration with Tier 1 and Tier 2 customers. TE developed an optical high speed multimedia network based on 1000 μm polymere optical fiber (POF) supporting data-speed of 25 Mbps and 150 Mbps.

Infotainment Cluster
DIP & SIP Switches
A DIP switch is a manual electronic package that is composed of a series of tiny switches. It has a rectangular casing and two parallel rows of connecting terminals. A SIP switch is a computer chip package that has a single row of connection pins.

Consumer Ports
Consumer ports facilitate the exchange of data between consumer devices and automotive infotainment systems.
Consumer Ports
MATEnet Modular and Scalable Connectors
TE plays a major role in connecting critical electronic vehicle networks that enable transmission of data from sensors and systems. TE’s MATEnet modular and scalable connectors have been able to show a data transmission rate of 100 Mbit/s and 1 Gbit/s according to IEEE 100BASE-T1/1000BASE-T1. This can be achieved with standard automotive connectors based on TE’s miniaturized NanoMQS termination system in combination with unshielded twisted-pair (UTP) cable or shielded twisted-pair (STP) cable.

Consumer Ports
Potentiometers
A potentiometer is a manually adjustable variable resistor that allows you to change and regulate the current flowing through a resistor.

Consumer Ports
Tactile Switches
Tactile switches provide tactile feedback to the user when the switch or button makes contact with the control panel underneath, which is usually a printed circuit board.

Consumer Ports
Through-Hole Resistors
A through-hole resistor is a fixed resistor that has long, pliable leads that can be stuck into a breadboard or hand- or wave-soldered into a printed circuit board. A through-hole resistor is used to reduce the flow of electrical current within a circuit. It’s commonly composed of carbon film, metal film, metal oxide film, thick film, or wirewound.

Consumer Ports
Snap Action Switches
A snap action switch is a mechanical switch that sends a rapid transfer of contacts from one position to another. Also known as micro switches, snap action switches can be momentary or maintained contact and come in subminiature, miniature, and standard styles.

Control Panels
Control panels provide centralized control functions for automotive infotainment functions.
Control Panels
MATEnet Modular and Scalable Connectors
TE plays a major role in connecting critical electronic vehicle networks that enable transmission of data from sensors and systems. TE’s MATEnet modular and scalable connectors have been able to show a data transmission rate of 100 Mbit/s and 1 Gbit/s according to IEEE 100BASE-T1/1000BASE-T1. This can be achieved with standard automotive connectors based on TE’s miniaturized NanoMQS termination system in combination with unshielded twisted-pair (UTP) cable or shielded twisted-pair (STP) cable.

Control Panels
Potentiometers
A potentiometer is a manually adjustable variable resistor that allows you to change and regulate the current flowing through a resistor.

Control Panels
DIP & SIP Switches
A DIP switch is a manual electronic package that is composed of a series of tiny switches. It has a rectangular casing and two parallel rows of connecting terminals. A SIP switch is a computer chip package that has a single row of connection pins.

Control Panels
Trimmer Resistors
A trimmer resistor is a type of variable resistor or adjustable potentiometer that can adjust, tune, and calibrate circuits. It is meant to never be seen or adjusted by the device’s user.

Control Panels
Snap Action Switches
A snap action switch is a mechanical switch that sends a rapid transfer of contacts from one position to another. Also known as micro switches, snap action switches can be momentary or maintained contact and come in subminiature, miniature, and standard styles.

Inline Connections
View TE's leading data connectivity portfolio of inline connector products supporting automotive infotainment applications.
Inline Connections
MATE-AX Miniaturized Coax Connector System
TE's MATE-AX automotive coax connector system provides an EMI resistant and miniaturized interconnection solution for coax lines. A highly robust coax connector system for analog signal and digital data transport applications, it delivers superior data rate performance up to 9GHz and up to 20GHz with optimized designs. TE’s MATE-AX connector system provides advanced automotive coaxial technology for data transmission performance. By offering a higher packaging density, MATE-AX terminals support size and weight reduction which contributes to higher fuel efficiency.

Inline Connections
Surface Mount Resistors
A surface mount resistor is a tiny rectangular ceramic body with silver conductive edges on either end. They provide the same functionality as the more traditional axially leaded resistors but has a lower power dissipation capacity and oftentimes a lower stray inductance and capacity.

Inline Connections
MATEnet Modular and Scalable Connectors
TE plays a major role in connecting critical electronic vehicle networks that enable transmission of data from sensors and systems. TE’s MATEnet modular and scalable connectors have been able to show a data transmission rate of 100 Mbit/s and 1 Gbit/s according to IEEE 100BASE-T1/1000BASE-T1. This can be achieved with standard automotive connectors based on TE’s miniaturized NanoMQS termination system in combination with unshielded twisted-pair (UTP) cable or shielded twisted-pair (STP) cable.

Inline Connections
Probe Pads
Probe pads are incorporated in circuitry to avoid damage to sensitive tiny electronic circuits in surface mount devices. Probe pads enable safe probing of circuitry when adjusting, setting up, measuring, or repairing tiny electronic circuitry.

Inline Connections
Tactile Switches
Tactile switches provide tactile feedback to the user when the switch or button makes contact with the control panel underneath, which is usually a printed circuit board.

Inline Connections
DIP & SIP Switches
A DIP switch is a manual electronic package that is composed of a series of tiny switches. It has a rectangular casing and two parallel rows of connecting terminals. A SIP switch is a computer chip package that has a single row of connection pins.
