Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Connector System : Cable-to-Board

• Connector Product Type : Connector Assembly

• Connector & Contact Terminates To : Printed Circuit Board

• Grounding Options : None

• Modular Jacks & Plugs Products : RJ Type Jacks & Plugs

• Modular Connector Style : Jack

• Number of Positions : 6

• Port Configuration : Single Port

• Port Matrix Configuration : 1 x 1

• Connector Contact Density : Standard

• PCB Mount Orientation : Vertical

• Number of Loaded Positions : 6

• Connector Profile : Standard

• Modular Jack Latch Orientation : Standard - Latch Down

• Contact Underplating Material : Nickel

• Contact Base Material : Phosphor Bronze

• Contact Mating Area Plating Material : Nickel (Ni)

• Contact Current Rating (Max) (A): 1.5

• PCB Contact Termination Area Plating Material : Tin

• Termination Method to PCB : Surface Mount

• Mating Alignment : Without

• Connector Mounting Type : Board Mount

• Panel Mount Feature : With

• Mating Entry Location : Bottom

• Housing Color : Black

• Housing Material : PA 9T GF

• Centerline (Pitch) : 1.27 mm [ .05 in ]

• Connector Height : 12.7 mm [ .5 in ]

• PCB Thickness (Recommended) : 1.57 mm [ .062 in ]

• Operating Temperature Range : -40 – 70 °C [ -40 – 158 °F ]

• Circuit Application : Signal

• Shielded : No

• Performance Category : Cat 3

• UL Flammability Rating : UL 94V-0
