Products
68C Plug & Play Accelerometers  1
  • Accelerometer Type MEMS DC
  • Plug & Play Accelerometer Sensor Type DC Response Plug & Play Accelerometers
  • Electrical Connection Integral Cable
  • Full Scale Output Voltage ±.1
  • Zero Acceleration Output ±25
  • Excitation Voltage 2 – 10
  • Frequency Response 0-1000 to 0-4000
  • Number of Axes 3
  • Material Stainless Steel
  • Weight 9
  • Plug & Play Accelerometer Mounting Type Screw
  • Operating Temperature Range -40 – 90
  • Acceleration Range (±) 100
  • Sensitivity .1 mV/g
  • Nonlinearity ±1
610 RATE SENSOR Rate & Inertial Sensors  1
  • Rate & Inertial Sensor Type Rate Sensors/Gyros
  • Excitation Voltage 5 – 16
  • Dimensions MM 14.6 x 10.2 x 7.6
  • Operating Temperature Range -40 – 105
  • Rate & Inertial Sensor Package Anodized Aluminium
  • Accuracy ±0.5% Non-Linearity
  • FS Range (±) DEG/SEC 18000
MODEL 4604 Plug & Play Accelerometers  1
  • Accelerometer Type MEMS DC
  • Plug & Play Accelerometer Sensor Type DC Response Plug & Play Accelerometers
  • Electrical Connection Integral Cable
  • Full Scale Output Voltage ±2
  • Zero Acceleration Output ±50
  • Excitation Voltage 4 – 30
  • Frequency Response 0-1000 to 0-4000
  • Number of Axes 1
  • Material Anodized Aluminum
  • Weight 10
  • Plug & Play Accelerometer Mounting Type Screw
  • Operating Temperature Range -55 – 125
  • Acceleration Range (±) 2
  • Sensitivity 10 mV/g
  • Nonlinearity ±.1
MODEL 4630M12 & 4630M14 Plug & Play Accelerometers  1
  • Accelerometer Type MEMS DC
  • Plug & Play Accelerometer Sensor Type DC Response Plug & Play Accelerometers
  • Electrical Connection Integral Cable
  • Full Scale Output Voltage ±5
  • Zero Acceleration Output ±50
  • Excitation Voltage 8 – 36
  • Frequency Response 0-1500
  • Number of Axes 3
  • Material Titanium
  • Weight 30
  • Plug & Play Accelerometer Mounting Type Screw
  • Operating Temperature Range -55 – 125
  • Acceleration Range (±) 2
  • Sensitivity 10 mV/g
  • Nonlinearity ±.1
633 RATE SENSOR Rate & Inertial Sensors  1
  • Rate & Inertial Sensor Type Rate Sensors/Gyros
  • Excitation Voltage 4.9 – 16
  • Dimensions MM 21.3 x 21.3 x 15.2
  • Operating Temperature Range -40 – 105
  • Rate & Inertial Sensor Package Stainless Steel
  • FS Range (±) G 100
  • Accuracy ±0.5% Non-Linearity
  • FS Range (±) DEG/SEC 6000
EPL Pressure Transducers  1
  • Pressure Transducer Sensor Type Miniature Pressure Transducers
  • Pressure Type Absolute
  • Pressure Transducer Supply Voltage 10
  • Port Material Stainless Steel
  • Pressure .35
  • Operating Temperature Range -40 – 120
  • Proof Pressure Range 10X FS
  • Pressure Range 0 – 0.35 bar
  • Output/Span 10 mV
  • Pressure Accuracy Down to ± .5% FSO
  • Options Body
EPB Pressure Transducers  1
  • Pressure Transducer Sensor Type Miniature Pressure Transducers
  • Pressure Type Absolute
  • Pressure Transducer Supply Voltage 10
  • Port Material Stainless Steel
  • Pressure .35
  • Operating Temperature Range -40 – 120
  • Proof Pressure Range 10X FS
  • Pressure Range 0 – 0.35 bar
  • Output/Span 10 mV
  • Pressure Accuracy Down to ± .5% FSO
  • Options Body
XP5 Pressure Transducers  1
  • Pressure Transducer Sensor Type Miniature Pressure Transducers
  • Pressure Type Absolute
  • Pressure Port/Fitting 10-32 UNF Male
  • Electrical Connection Integral connector
  • Pressure Transducer Supply Voltage 10
  • Port Material Titanium
  • Dimensions Hex 10
  • Pressure .5
  • Operating Temperature Range -40 – 120
  • Proof Pressure Range 2X FS
  • Pressure Range 0 – 0.5 bar
  • Output/Span .5 – 4.5 V
  • Pressure Accuracy Down to ± .25% FSO
  • Options Cable Length
EPRB-1 Pressure Transducers  1
  • Pressure Transducer Sensor Type Miniature Pressure Transducers
  • Pressure Type Absolute
  • Pressure Port/Fitting 10-32 UNF Male
  • Pressure Transducer Supply Voltage 5
  • Port Material Stainless Steel
  • Dimensions Dia 11
  • Pressure 3.5
  • Operating Temperature Range -40 – 150
  • Proof Pressure Range 1.5X FS
  • Pressure Range 0 – 10 bar
  • Output/Span .5 – 4.5 V
  • Pressure Accuracy ±0.25% FSO
  • Options Acceptance Test Report
64B Plug & Play Accelerometers  1
  • Accelerometer Type MEMS DC
  • Plug & Play Accelerometer Sensor Type DC Response Plug & Play Accelerometers
  • Electrical Connection Integral Cable
  • Full Scale Output Voltage ±.1
  • Zero Acceleration Output ±25
  • Excitation Voltage 2 – 10
  • Frequency Response 0-1400 to 0-4500
  • Number of Axes 1
  • Material Anodized Aluminum
  • Weight 1
  • Plug & Play Accelerometer Mounting Type Screw
  • Operating Temperature Range -40 – 121
  • Acceleration Range (±) 50
  • Sensitivity .04 mV/g
  • Nonlinearity ±1
Story

Application

Automotive Safety Testing

During collision testing, our sensors see what it takes to keep drivers safe behind the wheel.

Accelerometers collect thousands of data points during a vehicle crash test in a fraction of a second.  TE Connectivity (TE) offers one of the most comprehensive portfolios of test & measurement (T&M) sensors in the industry. Automotive design engineers use information gathered by accelerometers to develop vehicles that protect the drivers and passengers involved in accidents. We utilize advanced manufacturing processes and calibration equipment to provide customers with some of the most accurate sensors in the industry. The world's largest automakers trust our sensors to help ensure cars are ready to go-to-market.

Application

Automotive Safety Testing

During collision testing, our sensors see what it takes to keep drivers safe behind the wheel.

Accelerometers collect thousands of data points during a vehicle crash test in a fraction of a second.  TE Connectivity (TE) offers one of the most comprehensive portfolios of test & measurement (T&M) sensors in the industry. Automotive design engineers use information gathered by accelerometers to develop vehicles that protect the drivers and passengers involved in accidents. We utilize advanced manufacturing processes and calibration equipment to provide customers with some of the most accurate sensors in the industry. The world's largest automakers trust our sensors to help ensure cars are ready to go-to-market.
