DBAS Series Push Pull Electrical Connectors

The DEUTSCH DBAS series connectors deliver integrated, high-performance solutions for aerospace, military, and space applications. The DBAS 7 Series and DBAS 9 Series connectors are ideal for rack and panel equipment and feature a variety of customizable inserts, shell types, insert layouts, and finishes to meet your needs.

Both the DBAS 7 Series and DBAS 9 Series connectors are built for high-temperature, cryogenic, and pyrotechnic environments. They feature visual and sensitive push-pull locking with double keying system and wire sealing, making them highly reliable for harsh conditions.

• Compliant with SAE/AS81703 series III, UTE C 93-422 model HE 311 and ESA/SCC 3401
• Up to 1500 mating/unmating cycles
• Customizable design with a wide range of shell types, insert layouts, and finishes, including removable contacts size 6 to 22, crimp, solder and PCB types

Compliant with specifications:
SAE/AS81703 series III, UTE 93422 model HE 311 and ESA/SCC 3401

Connection Reliability:

• Visual and sensitive locking (blind mating)

• Double keying system to prevent any cross connection

• Leading clip preventing any accidental unmating on demand

• Interface and individual wire sealing

Large Range of Variants and Accessories:

• Mobile and “rack and panel” plugs, plugs with heavy duty lanyard

• Sealed receptacles and hermetic receptacles and feedthrough

• Removable contacts size 6 to 22, crimp, solder and PCB types

• Savers, protective caps and dummy receptacles

Custom Design for Integrated Solutions:

• Cryogenic and High Temperature versions

• Dead-Face systems

• Specials (High Speed, HF, pyrotechnic, 1553 bus)

• Compliant with SAE/AS81703 series III, UTE C 93-422 model HE 311 and MIL-DT 38999
• Up to 500 mating/unmating cycles, with variants available for up to 1500 cycles
• Customizable design with a wide range of shell types, insert layouts, and finishes, including removable contacts size 8 to 22, crimp, solder and PCB types

Compliant with specifications:

SAE/AS81703 series III, UTE  93422 model HE 311 and MIL-DTL-38999

Connection Reliability:

• Visual and sensitive locking (blind mating)

• Leading clip preventing any accidental unmating on demand

• Interface and individual wire sealing

Large Range of Variants and Accessories:

• Mobile and “rack and panel” plugs, plugs with heavy duty lanyard

• Removable contacts size 8 to 22, crimp, solder and PCB types

• High-density, hybrid signal and power layouts

Custom Design for Integrated Solutions:

• Integrated backshells

• Fiber Optic

• High speed solutions

• Rocket launch pad
• Satellites
