Please review product documents or contact us for the latest agency approval information.

Please Note: Use the Product Drawing for all design activity.

• Input Termination Type : Terminal Block

• Output Termination Type : Terminal Block

• Short Circuit Current Rating (kA): 100

• Overvoltage Category : III

• Operating Voltage (Max) (VAC): 480

• Motor Drive Input Current (A): 67

• Rated Load Power (kW): 37

• Product Weight (g): 43000

• Product Mount Type : Wall Mount

• Product Height : 248 mm [ 9.76 in ]

• Product Length : 468 mm [ 18.42 in ]

• Product Width : 280 mm [ 11.02 in ]

• Compatible with Motor Drive Type : 6 Pulse Diode Rectifier & SCR

• Rated Voltage & Power Efficiency : >98%

• Operating Altitude (Max) (m): 2000

• Target THDi @ Rated Power (%): 10 – 15

• Cooling Method : Active Air Cooling

• Certified To : EN 61558-2-20, UL/EN 61800-5-1

• Pollution Degree : PD2

• UL Flammability Rating : UL 94V-2

• IP Rating : IP20
