Products (208)
8-215570-6 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Cable-to-Board
  • PCB Mounting Orientation Vertical
  • Connector Style Paddle-Board
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Paddleboard
  • Board Standoff With
  • Product Type Connector
  • Number of Positions 16
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Termination Post Length 3.2
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • PCB Thickness (Recommended) 1.6
  • Height 5.1
  • Length 23.8
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
2-338095-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Wire-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Standard
  • Connector Type Housing
  • Board Standoff Without
  • Product Type Housing
  • Number of Positions 20
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Socket
  • Contact Base Material Phosphor Bronze
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • PCB Thickness (Recommended) 1.6
  • Height 12.4
  • Length 28.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 200
8-215570-2 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Cable-to-Board
  • PCB Mounting Orientation Vertical
  • Connector Style Paddle-Board
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Paddleboard
  • Board Standoff With
  • Product Type Connector
  • Number of Positions 12
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Termination Post Length 3.2
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • PCB Thickness (Recommended) 1.6
  • Height 5.1
  • Length 18.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
8-215570-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Cable-to-Board
  • PCB Mounting Orientation Vertical
  • Connector Style Paddle-Board
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Paddleboard
  • Board Standoff With
  • Product Type Connector
  • Number of Positions 10
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Termination Post Length 3.2
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • PCB Thickness (Recommended) 1.6
  • Height 5.1
  • Length 16.2
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
7-215460-4 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Right Angle
  • Shrouded Yes
  • Connector Style Receptacle
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 4
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Post Length 3.1
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Locking Latch Without
  • Centerline (Pitch) 1.27
  • Housing Entry Style Side
  • Housing Material Polyester - GF
  • Housing Color Red
  • Height 5.8
  • Length 7.1
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
8-215083-6 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Wire-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Low
  • Connector & Contact Terminates To Wire & Cable
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Male-On-Wire
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 16
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • Height 6.8
  • Accepts Wire Insulation Diameter Range .1 – .9
  • Length 23.8
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
7-215464-4 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 4
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Termination Area Plating Thickness 3 – 5
  • Contact Base Material Phosphor Bronze
  • Contact Mating Area Plating Thickness 3 – 5
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin
  • Termination Method to PC Board Through Hole
  • Termination Post Length 3.1
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • PCB Thickness (Recommended) 1.6
  • Height 6.9
  • Length .649
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
8-215083-2 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Wire-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Low
  • Connector & Contact Terminates To Wire & Cable
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Male-On-Wire
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 12
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • Height 6.8
  • Accepts Wire Insulation Diameter Range .1 – .9
  • Length 18.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
1-338069-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Receptacle
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Type of Connector Female-on-Board
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 10
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.4
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Socket
  • Contact Base Material Copper Alloy
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Termination Method to PC Board Surface Mount
  • Termination Post Length 5.3
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Connector Lock With
  • Mating Alignment Without
  • Mating Retention Type Locking Latch
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Entry Style Top
  • Housing Material PA 4.6
  • Housing Color Black
  • PCB Thickness (Recommended) 1.6
  • Height 6.9
  • Length 17.3
  • Operating Temperature Range -30 – 85
  • UL Flammability Rating UL 94V-0
  • Packaging Method Reel
  • Packaging Quantity 900
8-215079-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Receptacle
  • Profile Low
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Type of Connector Female-on-Board
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 10
  • Ejection Latches Without
  • Operating Voltage 100
  • Insulation Resistance 1000
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Termination Area Plating Thickness .003 – .005
  • Contact Base Material Phosphor Bronze
  • Contact Mating Area Plating Thickness .003 – .005
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Post Length 3.1
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Locking Latch Without
  • Centerline (Pitch) 1.27
  • Housing Entry Style Top
  • Housing Material Polyester - GF
  • Housing Color Red
  • Height 4
  • Length 14.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
Overview
Get to know the Micro-MaTch connectors

Miniaturized connectivity

TE’s miniature Micro-MaTch connector family provides a proven reliable connection. Its unique contact-spring system helps prevent fretting corrosion by absorbing movements between male and female contacts.

A contact concept that inspires. The Micro-MaTch contact concept is essentially different from other systems available. By its design, the traditional failure mode in tinplated connections, fretting corrosion, is prevented. The separation of the two basic functions of the contact system (contact force generation and wire termination), enables the optimization of both functions and leads to relatively simple contact shapes.

  1. The Micro-Match Contact System (English)

The Micro-MaTch contact helps prevent fretting corrosion, the traditional failure mode in tin-plated connections. Relative movements caused by vibrations/thermal expansion can be prevented so that a gas tight connection can make the Micro-MaTch contact spring system fretting corrosion resistant. See how the unique contact system works.

1.27

mm, one of the smallest systems available

2N

Contact force

UL

Approval

Fretting Corrosion free

That is why a high contact force of 2N and tinplating is required. The unique spring contact can now work properly to avoid fretting corrosion.

Features

  • Tin plated contact design
  • One of the smallest systems available at 1.27 mm
  • UL-recognized: File No. E28476, Vol. 23, Section 4
  • Guaranteed minimum contact force of 2.0N
  • Fretting corrosion proof thanks to additional positioning spring member
  • Fully plated contacts: no bare edges and no migration of corrosion products
  • Contacts fully protected by polyester housings, except for side-entry female board connector
  • Full range of application tooling from hand tool to fully automated equipment
  • Wire connectors supplied on-tape and suitable for (semi-) automatic mass termination of 28 AWG [0.08 mm2 to 0.09 mm2] ribbon cable

Applications

  • Pumps
  • Drivers
  • Control units
  • Navigation systems
  • Base stations
  • Set top boxes
  • Audio equipment
  • Dashboard systems

Is your application less demanding?

If broad temperature range, mating cycles and vibration resistance are less relevant in your application, TE also offers the more economical developed Value-line. Find out more below.

Get to know the Micro-MaTch connectors

Miniaturized connectivity

TE’s miniature Micro-MaTch connector family provides a proven reliable connection. Its unique contact-spring system helps prevent fretting corrosion by absorbing movements between male and female contacts.

A contact concept that inspires. The Micro-MaTch contact concept is essentially different from other systems available. By its design, the traditional failure mode in tinplated connections, fretting corrosion, is prevented. The separation of the two basic functions of the contact system (contact force generation and wire termination), enables the optimization of both functions and leads to relatively simple contact shapes.

  1. The Micro-Match Contact System (English)

The Micro-MaTch contact helps prevent fretting corrosion, the traditional failure mode in tin-plated connections. Relative movements caused by vibrations/thermal expansion can be prevented so that a gas tight connection can make the Micro-MaTch contact spring system fretting corrosion resistant. See how the unique contact system works.

1.27

mm, one of the smallest systems available

2N

Contact force

UL

Approval

Fretting Corrosion free

That is why a high contact force of 2N and tinplating is required. The unique spring contact can now work properly to avoid fretting corrosion.

Features

  • Tin plated contact design
  • One of the smallest systems available at 1.27 mm
  • UL-recognized: File No. E28476, Vol. 23, Section 4
  • Guaranteed minimum contact force of 2.0N
  • Fretting corrosion proof thanks to additional positioning spring member
  • Fully plated contacts: no bare edges and no migration of corrosion products
  • Contacts fully protected by polyester housings, except for side-entry female board connector
  • Full range of application tooling from hand tool to fully automated equipment
  • Wire connectors supplied on-tape and suitable for (semi-) automatic mass termination of 28 AWG [0.08 mm2 to 0.09 mm2] ribbon cable

Applications

  • Pumps
  • Drivers
  • Control units
  • Navigation systems
  • Base stations
  • Set top boxes
  • Audio equipment
  • Dashboard systems

Is your application less demanding?

If broad temperature range, mating cycles and vibration resistance are less relevant in your application, TE also offers the more economical developed Value-line. Find out more below.

8-215570-6 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Cable-to-Board
  • PCB Mounting Orientation Vertical
  • Connector Style Paddle-Board
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Paddleboard
  • Board Standoff With
  • Product Type Connector
  • Number of Positions 16
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Termination Post Length 3.2
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • PCB Thickness (Recommended) 1.6
  • Height 5.1
  • Length 23.8
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
2-338095-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Wire-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Standard
  • Connector Type Housing
  • Board Standoff Without
  • Product Type Housing
  • Number of Positions 20
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Socket
  • Contact Base Material Phosphor Bronze
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • PCB Thickness (Recommended) 1.6
  • Height 12.4
  • Length 28.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 200
8-215570-2 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Cable-to-Board
  • PCB Mounting Orientation Vertical
  • Connector Style Paddle-Board
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Paddleboard
  • Board Standoff With
  • Product Type Connector
  • Number of Positions 12
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Termination Post Length 3.2
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • PCB Thickness (Recommended) 1.6
  • Height 5.1
  • Length 18.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
8-215570-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Cable-to-Board
  • PCB Mounting Orientation Vertical
  • Connector Style Paddle-Board
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Paddleboard
  • Board Standoff With
  • Product Type Connector
  • Number of Positions 10
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Termination Post Length 3.2
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • PCB Thickness (Recommended) 1.6
  • Height 5.1
  • Length 16.2
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
7-215460-4 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Right Angle
  • Shrouded Yes
  • Connector Style Receptacle
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 4
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Post Length 3.1
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Locking Latch Without
  • Centerline (Pitch) 1.27
  • Housing Entry Style Side
  • Housing Material Polyester - GF
  • Housing Color Red
  • Height 5.8
  • Length 7.1
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
8-215083-6 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Wire-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Low
  • Connector & Contact Terminates To Wire & Cable
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Male-On-Wire
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 16
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • Height 6.8
  • Accepts Wire Insulation Diameter Range .1 – .9
  • Length 23.8
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
7-215464-4 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 4
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Termination Area Plating Thickness 3 – 5
  • Contact Base Material Phosphor Bronze
  • Contact Mating Area Plating Thickness 3 – 5
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin
  • Termination Method to PC Board Through Hole
  • Termination Post Length 3.1
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • PCB Thickness (Recommended) 1.6
  • Height 6.9
  • Length .649
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
8-215083-2 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Wire-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Plug
  • Profile Low
  • Connector & Contact Terminates To Wire & Cable
  • Wire/Cable Type Ribbon Cable
  • Connector Type Connector Assembly
  • Type of Connector Male-On-Wire
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 12
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Base Material Phosphor Bronze
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to Wire/Cable Insulation Displacement Crimp (IDC)
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Material Polyester - GF
  • Housing Color Red
  • Insulation Diameter .9
  • Wire/Cable Size .08 – .09 mm²
  • Height 6.8
  • Accepts Wire Insulation Diameter Range .1 – .9
  • Length 18.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
1-338069-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Receptacle
  • Profile Standard
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Type of Connector Female-on-Board
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 10
  • Ejection Latches Without
  • Insulation Resistance 1000
  • Operating Voltage 100
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.4
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Socket
  • Contact Base Material Copper Alloy
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Termination Method to PC Board Surface Mount
  • Termination Post Length 5.3
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention Without
  • Mating Alignment Type Polarization
  • Mating Connector Lock With
  • Mating Alignment Without
  • Mating Retention Type Locking Latch
  • Mating Retention Without
  • Polarization With
  • Centerline (Pitch) 1.27
  • Housing Entry Style Top
  • Housing Material PA 4.6
  • Housing Color Black
  • PCB Thickness (Recommended) 1.6
  • Height 6.9
  • Length 17.3
  • Operating Temperature Range -30 – 85
  • UL Flammability Rating UL 94V-0
  • Packaging Method Reel
  • Packaging Quantity 900
8-215079-0 Ribbon Cable Connectors
  • Header Type Pin Header
  • Connector System Board-to-Board
  • PCB Mounting Orientation Vertical
  • Shrouded Yes
  • Connector Style Receptacle
  • Profile Low
  • Connector & Contact Terminates To Printed Circuit Board
  • Connector Type Connector Assembly
  • Type of Connector Female-on-Board
  • Board Standoff Without
  • Product Type Connector
  • Number of Positions 10
  • Ejection Latches Without
  • Operating Voltage 100
  • Insulation Resistance 1000
  • Daisy Chain Without
  • Solder Tail Contact Plating Material Tin over Nickel
  • Contact Current Rating (Max) 1.5
  • Contact Mating Area Plating Material Tin over Nickel
  • Contact Type Pin
  • Contact Termination Area Plating Thickness .003 – .005
  • Contact Base Material Phosphor Bronze
  • Contact Mating Area Plating Thickness .003 – .005
  • Vacuum Tape Without
  • Contact Transmits (Typical) Signal (Data)
  • Contact Design Dual Beam
  • Contact Termination Area Plating Material Tin over Nickel
  • Termination Method to PC Board Through Hole
  • Termination Post Length 3.1
  • Panel Mount Feature Without
  • PCB Mount Alignment Without
  • PCB Mount Retention With
  • PCB Mount Retention Type Kink
  • Mating Alignment Without
  • Mating Retention Without
  • Polarization Without
  • Locking Latch Without
  • Centerline (Pitch) 1.27
  • Housing Entry Style Top
  • Housing Material Polyester - GF
  • Housing Color Red
  • Height 4
  • Length 14.7
  • Operating Temperature Range -40 – 105
  • UL Flammability Rating UL 94V-0
  • Packaging Method Box & Carton
  • Packaging Quantity 250
