Products
SERIES I   1
  • Tolerance β-Value ±.5
  • Discrete NTC Sensor Type Epoxy Coated NTC Thermistor
  • Beta 25/85 Value 3694
  • Wire Connection Open End
  • Discrete NTC Wire Length 76
  • Resistance (at 25°C) 2.252
  • Maximum Temperature 125
  • Discrete NTC Ambient Temperature Range -40 – 125
  • Temperature Accuracy ± .2 from 0 – 70
  • Wire/Cladding Connection 32 AWG (.2mm) Alloy 180 Tin Plated
  • Discrete NTC Package Epoxy Radial Discrete
GAG10K3976B1 Discrete NTC  1
  • Discrete NTC Sensor Type NTC Thermistor
  • Tolerance β-Value 2
  • Wire Connection Open End
  • Discrete NTC Wire Length 65
  • Resistance (at 25°C) 10
  • Tolerance Resistance ± 1
  • Discrete NTC Ambient Temperature Range -40 – 250
  • Temperature Accuracy ± .22 @ 25
  • Wire/Cladding Connection Dumet Ni/Fe Copper Clad, .2mm OD
  • Discrete NTC Package Glass Radial Discrete
LL-01 - RELAY VERSION Ultrasonic Sensors  1
  • Ultrasonic Sensor Type Point Liquid Level Sensors
  • Ultrasonic Sensor Style Gap
  • Cable 1 Feet
  • Output 30 V, 3 W Relay
  • Input 5 - 30 VDC
  • Operating Temperature Range -30 – 80
  • Pressure Range 250 psi
  • Process Connection 1/2"NPT
  • Actuation Point/Sensing Range .25 Inches
CAT-RTD0046 RTD Sensor Elements  1
  • Model Number PTFC101A1A0
  • RTD Element Type Platinum Thin Film Temperature Element
  • Element Material Platinum
  • Lead Wire Style Ag
  • Wire/Cladding Type Ni/Au
  • Connector Type Open Ends
  • Length (Body) 2.3
  • Wire Diameter .25
  • Width (Body) 2
  • Wire Length 10
  • Height (Body) 1.1
  • T_ref for Resistance 0
  • Maximum Temperature 200
  • Accuracy (at T_ref) ± .1
  • TCR at (T1 and T2) 3850
  • T1 and T2 for TCR 0 and +100
  • Ambient Temperature Range -30 – 200
  • T_ref for Accuracy 0
  • Resistance (at T_ref) 100 (0 °C)
  • Element Package Ceramic
  • Wire Count 2
  • Tolerance Class Class T (AA) / F0.1
MINISENSE Piezo Film Sensors  1
  • Piezo Film Sensor Type Element
  • Features Laminated
HTU21D Humidity Sensor Components  1
  • Humidity Sensor Component Product Type RHT
  • Humidity Sensor Component Sensor Type Digital
  • Supply Voltage (Peak) 3.8
  • Current Consumption .014
  • Humidity Operating Range 0 – 100
  • Operating Temperature Range -40 – 125
KMA36 Magnetic Sensors  1
  • Magnetic Sensor Product Type Magnetic Angle Sensor
  • Typical Operating Voltage 3 – 5.5
  • Typical Average Current 10 – 30
  • Sleep Current 1.2
  • Operating Temperature Range -25 – 85
  • Signal Output Analog
  • Data Update Rate 24 – 720
  • I2C Clockrate Up to 100
  • Magnetic Sensor Package TSSOP20
  • Resolution 13
4020,4030 Plug & Play Accelerometers  1
  • Accelerometer Type MEMS DC
  • Plug & Play Accelerometer Sensor Type DC Response Plug & Play Accelerometers
  • Electrical Connection Integral Cable
  • Full Scale Output Voltage ±2
  • Excitation Voltage 5 – 30
  • Zero Acceleration Output 2500 ±100
  • Frequency Response 0-200
  • Number of Axes 2
  • Weight 50
  • Material Nylon 6-6
  • Plug & Play Accelerometer Mounting Type Screw
  • Operating Temperature Range -40 – 85
  • Acceleration Range (±) 6
  • Sensitivity 333 mV/g
  • Nonlinearity ±1
MS4525 Board Level Pressure Sensors  1
  • Board Level Pressure Sensor Type Analog Pressure Sensor Modules
  • Board Level Pressure Sensor Style Differential
  • Board Level Pressure Sensor Supply Voltage 3.3
  • Dimensions 12.5 x 9.9
  • Operating Temperature Range -10 – 85
  • Output/Span 10 - 90% Vdc
  • Board Level Pressure Sensor Accuracy ±0.25% Span
  • Board Level Pressure Sensor Package 8 pin DIL
  • Options No Option
801X-01 Plug & Play Accelerometers  1
  • Accelerometer Type IEPE
  • Plug & Play Accelerometer Sensor Type AC Response Plug & Play Accelerometers
  • Electrical Connection 2-Pin Connector
  • Full Scale Output Voltage ±5
  • Excitation Voltage 18 – 30
  • Excitation Current 2 – 10
  • Frequency Response 0.5-7000 to 0.5-18000
  • Number of Axes 1
  • Weight 93
  • Material Stainless Steel
  • Plug & Play Accelerometer Mounting Type Stud
  • Operating Temperature Range -55 – 125
  • Acceleration Range (±) 10
  • Sensitivity 10 mV/g
  • Nonlinearity ±1
Story
HVACR / Building Equipment

Application

Sensors for HVACR and Building Equipment

TE Connectivity (TE) sensors play a major role in regulating heating, ventilation, air conditioning, and refrigeration systems. Download our solution guide to learn more about our latest offerings in HVACR.

Our indoor environments are becoming more comfortable and efficient to maintain due to the growth of innovative technologies and sensor networks that regulate heating, ventilation and air conditioning.  Sensors encounter many diverse application needs throughout the HVAC and refrigeration industries. Temperature, humidity and pressure sensors are the most commonly used sensors for HVAC and building equipment applications. Temperature sensors can monitor ambient conditions as well as liquids and gases that are used to heat and cool the environment. Pressure sensors and transducers can operate in the same way to provide efficiency.  Humidity sensors can be integrated into humidification systems or dehumidification systems to increase comfort. In some cases, these sensor types are integrated into the same device.  Our global network of engineers provide full support of application-specific, standard and custom requirements, from product concept through manufacturing. Fast-paced product development time lines are met with rapid prototyping as TE creates solutions for its customers. Leading products include:

ASIC Compensation icon

ASIC Compensation

digital output icon

Digital Output Option

sensing technology icon

Simple & Reliable Sensing Technology

  1. Exploring Sensors in HVACR Systems (English)

Sensors are an integral part of most heating, ventilation, air-conditioning, and refrigeration (HVACR) systems — helping to not only maintain a comfortable indoor climate but also to enable the HVACR system to perform properly. Watch this webinar to learn how sensors and HVACR systems are evolving to meet the industry needs for much finer control and improved performance and efficiency.

HVACR Sensors

TE designs and manufactures sensors for vibration, liquid level, position, and fluid property. From motor vibration monitoring, to water flow in boiler systems, the TE portfolio allows integrators to specify various sensor types within one system from a single supplier. As a global designer and manufacturer of sensors and sensor-based systems, TE provides support to HVACR engineers in both the development and instrumentation of HVACR systems. Our sensors are designed and manufactured to exacting specifications, often on a custom basis. Together with our customers, we are working to solve today's biggest application challenges in new and creative ways.

HVACR Application Solutions
