BOILER PROBE WITH INTEGRATED CONNECTOR NTC Probes and Assemblies  1
  • Sensor Type HVAC/R
  • Resistance @ 25°C [KΩ] 10
  • β-Value(25/85) 3976
  • Operating Temperature Range -40 – 125
  • T_ref for Resistance 25
  • Temperature Accuracy ± 1 from 25 – 85
  • Package Brass Immersion
  • Connector Type 2 Pin
  • Tolerance Resistance % ±1
  • Operating Temperature DEGF -40 – 257
PIPE PROBE NTC Probes and Assemblies  1
  • Sensor Type HVAC/R
  • Resistance @ 25°C [KΩ] 10
  • β-Value(25/85) 3435
  • Wire/Cladding 26 AWG Stranded Insulated Leads
  • Wire Length 1000
  • Operating Temperature Range 25 - 85
  • T_ref for Resistance 25
  • Temperature Accuracy ± 1 from 25 – 85
  • Package 1/2 inch Pipe Mount
  • Connector Type Open End
  • Tolerance Resistance % ±2
  • Operating Temperature DEGF -40 – 257
SINGLE INSULATED 5X20 MM NTC Probes and Assemblies  1
  • Sensor Type HVAC/R
  • Resistance @ 25°C [KΩ] 10
  • β-Value(25/85) 3435
  • Wire/Cladding 26 AWG Stranded Insulated Leads
  • Wire Length 1000
  • Operating Temperature Range -40 – 125
  • T_ref for Resistance 25
  • Temperature Accuracy ± .22 @ 25
  • Package Overmold TPE
  • Connector Type Open End
  • Tolerance Resistance % ±1
  • Operating Temperature DEGF -40 – 257
TPE OM NTC PROBE WITH SS HOUSING 6X50 MM NTC Probes and Assemblies  1
  • Sensor Type HVAC/R
  • Resistance @ 25°C [KΩ] 10
  • β-Value(25/85) 3435
  • Wire/Cladding 26 AWG Stranded Insulated Leads
  • Wire Length 1000
  • Operating Temperature Range -40 – 125
  • T_ref for Resistance 25
  • Temperature Accuracy ± .22 @ 25
  • Package Overmold TPE with SS housing
  • Connector Type Open End
  • Tolerance Resistance % ±1
  • Operating Temperature DEGF -40 – 257
TPE OVERMOULDED PROBE DIA 5X20 MM NTC Probes and Assemblies  1
  • Sensor Type HVAC/R
  • Resistance @ 25°C [KΩ] 10
  • β-Value(25/85) 3435
  • Wire/Cladding 26 AWG Stranded Insulated Leads
  • Wire Length 1000
  • Operating Temperature Range -40 – 125
  • T_ref for Resistance 25
  • Temperature Accuracy ± .22 @ 25
  • Package Overmold TPE
  • Connector Type Open End
  • Tolerance Resistance % ±1
  • Operating Temperature DEGF -40 – 257
UREA TEMP PROBE W INTEGRATED CONNECTOR NTC Probes and Assemblies  1
  • Sensor Type Immersion
  • Resistance @ 25°C [KΩ] 10
  • β-Value(25/85) 3976
  • Operating Temperature Range -40 – 125
  • T_ref for Resistance 25
  • Temperature Accuracy ± 1 from 25 – 85
  • Package Overmold TPE with SS housing
  • Connector Type Integrated
  • Tolerance Resistance % ±1
  • Operating Temperature DEGF -40 – 257
