WEFTEC 2016

Industry Tradeshow

WEFTEC

Learn how TE Connectivity (TE) is a leader in the water usage and resources monitoring market with long standing industry experience in the design and manufacturing of water level sensors and systems.

September 26-28, 2016

New Orleans, Louisiana
Morial Convention Center
Booth# 1346 Hall B2

Join TE Connectivity (TE) at WEFTEC in New Orleans, Louisiana from September 26-28, 2016. TE is one of the largest connectivity and sensor companies in the world, with innovative sensor solutions that help customers transform concepts into smart, connected creations. Visit TE at Booth# 1346, Hall B2 to explore our sensor portfolio and discover the many ways our TruBlue and KPSI water level sensors can help empower your designs and products.

  1. Enter the World of Sensors

Sensors enhance our capacity to observe and report on the world around us. What a sensor sees can be the difference between that which is imagined and that which is possible.

8042-01 Plug & Play Accelerometers  1
  • Sensor Type AC Response Plug & Play Accelerometers
  • Accelerometer Type IEPE
  • Full Scale Output Voltage ±5
  • Excitation Current 2 – 10
  • Electrical Connection Integral Cable
  • Excitation Voltage 18 – 30
  • Frequency Response 1-4000 to 1-10000
  • Number of Axes 1
  • Material Titanium
  • Weight 70
  • Mounting Type Stud
  • Operating Temperature -20 – 80
  • Overall Acceleration Range (±) 10 – 500
  • Acceleration Range (±) 10
  • Sensitivity Range 10 – 500 mV/g
  • Sensitivity 10 mV/g
  • Nonlinearity ±1
8042-AR, 8042-AP Plug & Play Accelerometers  1
  • Sensor Type AC Response Plug & Play Accelerometers
  • Accelerometer Type 4 – 20 mA Loop Power
  • Electrical Connection Integral Cable
  • Excitation Voltage 12 – 30
  • Full Scale Output Current 4 – 20
  • Frequency Response 10-5000
  • Number of Axes 1
  • Material Titanium
  • Weight 70
  • Mounting Type Stud
  • Operating Temperature -20 – 80
  • Overall Acceleration Range (±) 5 – 100
  • Acceleration Range (±) 10
  • Sensitivity Range .16 – 3.2 mA/g
  • Sensitivity .16 mA/g
  • Nonlinearity ±1
8042-VR, 8042-VP Plug & Play Accelerometers  1
  • Sensor Type AC Response Plug & Play Accelerometers
  • Accelerometer Type 4 – 20 mA Loop Power
  • Electrical Connection Integral Cable
  • Excitation Voltage 12 – 30
  • Full Scale Output Current 4 – 20
  • Frequency Response 3-1000
  • Number of Axes 1
  • Material Titanium
  • Weight 70
  • Mounting Type Stud
  • Operating Temperature -20 – 80
  • Overall Acceleration Range (±) 0-.5 – 0-5
  • Acceleration Range (±) .5
  • Sensitivity Range 3.2 – 32 mA/in/sec
  • Sensitivity 16 mA/in/sec
  • Nonlinearity ±1
AST4500/4510 Pressure Transducers  1
  • Sensor Type Liquid Level Pressure Transducers
  • Type Gage
  • Pressure Port/Fitting 1/2 MNPT
  • Supply Voltage 10 – 28
  • Electrical Connection Conduit 10 ft
  • Port Material 316L
  • Operating Temperature -40 – 80
  • Pressure Range 0 – 1 to 100 psi
  • Output/Span 0.5 – 4.5 V
  • Accuracy ±0.25% FSO
  • Overpressure 2X, Min
  • Options Custom Cable Lengths
AST4520 Pressure Transducers  1
  • Sensor Type Liquid Level Pressure Transducers
  • Type Gage
  • Pressure Port/Fitting 1/2 MNPT Flush
  • Supply Voltage 10 – 28
  • Electrical Connection Conduit 25 ft
  • Port Material 316L
  • Operating Temperature -40 – 80
  • Pressure Range 0 – 2 to 15 psi
  • Output/Span 0.5 – 4.5 V
  • Accuracy ±0.25% FSO
  • Overpressure 2X, Min
  • Options Custom Cable Lengths
AST4530 Pressure Transducers  1
  • Sensor Type Liquid Level Pressure Transducers
  • Type Gage
  • Pressure Port/Fitting None
  • Supply Voltage 10 – 28
  • Electrical Connection Conduit 25 ft
  • Port Material PTFE
  • Operating Temperature -40 – 80
  • Pressure Range 0 – 2 to 30 psi
  • Output/Span 0.5 – 4.5 V
  • Accuracy ±0.25% FSO
  • Overpressure 2X, Min
  • Options Custom Cable Lengths
AST45PT Pressure Transducers  1
  • Sensor Type Liquid Level Pressure Transducers
  • Type Gage
  • Pressure Port/Fitting 1/2 MNPT
  • Supply Voltage 10 – 28
  • Electrical Connection Conduit 10 ft
  • Port Material 316L
  • Operating Temperature 0 – 60
  • Pressure Range 0 – 1 to 100 psi
  • Output/Span 1 – 5 V
  • Accuracy ±0.1% FSO
  • Overpressure 2X, Min
  • Options Custom Cable Lengths
KPSI 27 Water-Level Sensors  1
  • Sensor Type Pressure Transducers
  • Type Absolute
  • Pressure Port/Fitting 1/2 MNPT
  • Output/Span 0 – 10 V
  • Supply Voltage 9 – 28
  • Electrical Connection 1/2 MNPT Gland
  • Port Material 316 SS
  • Pressure Range 0 – 1 to 2000 psi
  • Accuracy ± .25% FS
  • Operating Temperature -20 – 60
  • Overpressure 2X FS
  • Options Lightning Protection
KPSI 28 Water-Level Sensors  1
  • Sensor Type Pressure Transducers
  • Type Absolute
  • Pressure Port/Fitting 1/2 MNPT
  • Output/Span 0 – 10 V
  • Supply Voltage 9 – 28
  • Electrical Connection 1/2 MNPT Gland
  • Port Material 316 SS
  • Pressure Range 0 – 1 to 2000 psi
  • Accuracy ± .5% FS
  • Operating Temperature -20 – 60
  • Overpressure 2X FS
  • Options Lightning Protection
KPSI 30 Water-Level Sensors  1
  • Sensor Type Pressure Transducers
  • Type Absolute
  • Pressure Port/Fitting 1/2 MNPT
  • Output/Span 0 – 10 V
  • Supply Voltage 9 – 28
  • Electrical Connection 1/2 MNPT Gland
  • Port Material 316 SS
  • Pressure Range 0 – 1 to 500 psi
  • Accuracy ± .1% FS
  • Operating Temperature -20 – 60
  • Overpressure 2X FS
  • Options Lightning Protection
